Switch Port Configuration
To display the following form, go to the Switch Ports Configuration form. Select a Switch Port number.
This form allows you to configure settings for individual switch ports.
The following table describes the Switch Port Configuration controls:
Table 101
Switch Port Configuration controls
Control
Switch Port State
RMON Instrumentation
Media Setting
VLAN Tagging
Description
Enables or disables the port.
Enables or disables Remote Monitoring for the port. RMON must be
enabled for RMON statistics and history sampling to function.
Configures the port's transmission media, as follows:
fiber
copper
auto
This field applies only to uplink ports.
Disables or enables VLAN tagging for this port. It is disabled by default.
