3.4 REAMING (Cycle 201,
DIN/ISO: G201)
Cycle run
1 The TNC positions the tool in the spindle axis at rapid traverse FMAX
to the entered setup clearance above the workpiece surface.
2 The tool reams to the entered depth at the programmed feed
rate F.
3 If programmed, the tool remains at the hole bottom for the entered
dwell time.
4 The tool then retracts to the setup clearance at the feed rate F, and
from there—if programmed—to the 2nd setup clearance at FMAX.
Please note while programming:
Program a positioning block for the starting point (hole
center) in the working plane with radius compensation R0.
The algebraic sign for the cycle parameter DEPTH
determines the working direction. If you program DEPTH
= 0, the cycle will not be executed.
Danger of collision!
Enter in MP7441 bit 2 whether the TNC should output an
error message (bit 2=1) or not (bit 2=0) if a positive depth
is entered.
Keep in mind that the TNC reverses the calculation for pre-
positioning when a positive depth is entered. This
means that the tool moves at rapid traverse in the tool axis
to setup clearance below the workpiece surface!
HEIDENHAIN iTNC 530 77
