4.7 THREAD
MILLING/COUNTERSINKING
(Cycle 263, DIN/ISO: G263)
Cycle run
1 The TNC positions the tool in the spindle axis at rapid traverse FMAX
to the entered setup clearance above the workpiece surface.
Countersinking
2 The tool moves at the feed rate for pre-positioning to the
countersinking depth minus the setup clearance, and then at the
feed rate for countersinking to the countersinking depth.
3 If a setup clearance to the side has been entered, the TNC
immediately positions the tool at the feed rate for pre-positioning
to the countersinking depth.
4 Then, depending on the available space, the TNC makes a
tangential approach to the core diameter, either tangentially from
the center or with a pre-positioning move to the side, and follows
a circular path.
Countersinking at front
5 The tool moves at the feed rate for pre-positioning to the
countersinking depth at front.
6 The TNC positions the tool without compensation from the center
on a semicircle to the offset at front, and then follows a circular
path at the feed rate for countersinking.
7 The TNC then moves in a semicircle to the hole center.
Thread milling
8 The TNC moves the tool at the programmed feed rate for pre-
positioning to the starting plane for the thread. The starting plane
is determined from the thread pitch and the type of milling (climb
or up-cut).
9 Then the tool moves tangentially on a helical path to the thread
diameter and mills the thread with a 360° helical motion.
10 After this, the tool departs the contour tangentially and returns to
the starting point in the working plane.
11 At the end of the cycle, the TNC retracts the tool at rapid
traverse to the setup clearance, or—if programmed—to the
2nd setup clearance.
120 Fixed Cycles: Tapping / Thread Milling
