HEIDENHAIN ITNC 530 - CYCLE PROGRAMMING User Manual page 393

3 TCH PROBE 416 DATUM CIRCLE CENTER
Q273=+35 ;CENTER IN 1ST AXIS
Q274=+35 ;CENTER IN 2ND AXIS
Q262=50 ;NOMINAL DIAMETER
Q291=+90 ;ANGLE OF 1ST HOLE
Q292=+180 ;ANGLE OF 2ND HOLE
Q293=+270 ;ANGLE OF 3RD HOLE
Q261=+15 ;MEASURING HEIGHT
Q260=+10 ;CLEARANCE HEIGHT
Q305=1 ;NO. IN TABLE
Q331=+0 ;DATUM
Q332=+0 ;DATUM
Q303=+1 ;MEAS. VALUE TRANSFER
Q381=0 ;PROBE IN TS AXIS
Q382=+0 ;1ST CO. FOR TS AXIS
Q383=+0 ;2ND CO. FOR TS AXIS
Q384=+0 ;3RD CO. FOR TS AXIS
Q333=+0 ;DATUM
Q320=0 ;SETUP CLEARANCE
4 CYCL DEF 247 DATUM SETTING
Q339=1 ;DATUM NUMBER
6 CALL PGM 35KLZ
7 END PGM CYC416 MM
HEIDENHAIN iTNC 530
Center of the bolt hole circle: X coordinate
Center of the bolt hole circle: Y coordinate
Diameter of the bolt hole circle
Polar coordinate angle for 1st hole center
Polar coordinate angle for 2nd hole center
Polar coordinate angle for 3rd hole center
Coordinate in the touch probe axis in which the measurement is
made
Height in the touch probe axis at which the probe can traverse
without collision
Enter center of bolt hole circle (X and Y) in line 1
In the preset table PRESET.PR, save the calculated datum
referenced to the machine-based coordinate system (REF system)
Do not set a datum in the touch probe axis
No function
No function
No function
No function
Safety clearance in addition to MP6140
Activate new preset with Cycle 247
Part program call
1
2
3
