Specifications
Interpolation
Block processing time
3-D straight line without radius
compensation
Axis feedback control
Range of traverse
Spindle speed
Error compensation
Data interfaces
Surrounding temperature
HEIDENHAIN iTNC 530
Linear in 4 axes
Linear in 5 axes (subject to export permit) (software option 1)
Circular in 2 axes
Circular in 3 axes with tilted working plane (software option 1)
Helix:
Combination of circular and linear motion
Spline:
Execution of splines (3rd degree polynomials)
3.6 ms
0.5 ms (software option 2)
Position loop resolution: Signal period of the position encoder/1024
Cycle time of position controller: 1.8 ms
Cycle time of speed controller: 600 µs
Cycle time of current controller: minimum 100 µs
Maximum 100 m (3937 inches)
Maximum 40 000 rpm (with 2 pole pairs)
Linear and nonlinear axis error, backlash, reversal peaks during circular movements,
thermal expansion
Stick-slip friction
One each RS-232-C /V.24 and RS-422 / V.11 max. 115 kilobaud
Expanded interface with LSV-2 protocol for external operation of the TNC over the
interface with HEIDENHAIN software TNCremo.
Ethernet interface 100BaseT
Approx. 2 to 5 megabaud (depending on file type and network load)
USB 2.0 interface
For pointing (mouse) devices and block devices (memory sticks, hard disks, CD-ROM
drives)
Operation: 0 °C to +45 °C
Storage: –30 °C to +70 °C
