HEIDENHAIN ITNC 530 - 6-2010 DIN-ISO PROGRAMMING User Manual page 108

Select smarT.NC programs
Programs created in the smarT.NC operating mode can be opened in
the Programming and Editing mode with either the smarT.NC editor
or the conversational editor. By default the TNC always opens .HU and
.HC programs with the smarT.NC editor. If you want to open the
programs in the conversational editor, proceed as follows:
Call the file manager
With the arrow keys or the soft keys you can move the highlight to an
.HU or .HC file:
Moves the highlight from the left to the right window,
and vice versa.
Moves the highlight up and down within a window.
Moves the highlight one page up or down within a
window.
Shift the soft-key row.
Select the submenu for selecting the editor.
Open the .HU or .HC program with the conversational
editor.
Open the .HU program with the smarT.NC editor.
Open the .HC program with the smarT.NC editor.
108 Programming: Fundamentals, File Management
