The following functions help you to navigate in the form. You can also
use the mouse to use the form.
Functions
Jump to previous function
Jump to next function
Select the next element
Select the previous element
Axis swapping function: Open the list of available axes
Switch the function on/off if the cursor is on a check
box
Reset the global program settings:
Deactivate all functions
Set all entered values to 0, set feed rate factor to
100. Set basic rotation = 0 if no basic rotation is
active in the basic rotation menu or in the ROT
column of the active preset in the preset table.
Otherwise the TNC activates the basic rotation
entered there
Discard all changes since the form was last called
Deactivate all active functions. The entered or adjusted
values remain
Save all changes and close the form
HEIDENHAIN iTNC 530
Key/
Soft key
351
