Figure 6-2 MPUF internal structure
(2)
(1)
(1) Memory bar slot
(3) CF card slot
Figure 6-3 MSCA internal structure
(1)
(1) VPM slot
(3) ESM slot 1
(3)
(2) SIC slot
(2)
(3)
(2) VCPM slot
(4) ESM slot 0
6-2
(4)
