3Com MSR 50-40 ROUTER. Installation Manual page 14

Figure 1-3 Front panel of the MSR 50-60
(1) (2) (6)
(8)
(1) CF card LED
(3) SIC slot 1
(5) SIC slot 3
(7) FIC slot 5
(9) FIC slot 7
(11) FIC slot 9
4) Rear view of MSR 50-60
Figure 1-4 Rear view of MSR 50-60
(7)
(1) MSCA slot
(3) System power 1 slot
(5) System power socket
(7) Fan slot
(4) (5) (3)
(10) (12) (7)
1-4
(9) (11)
(2) CF card
(4) SIC slot 2
(6) SIC slot 4
(8) FIC slot 6
(10) FIC slot 8
(12) FIC slot 10
(6)
(5)
(2) System power 2 slot
(4) System power 0 slot
(6) Grounding terminal
(1)
(2)
(3)
(4)
