Diagnostics and Troubleshooting
Removing Stuck Cartridges
Figure 15 Removing
Mounting Brackets
(Left Side Shown)
56
Remove the power and SCSI cables from their connectors on
2
the back panel of the ValueLoader.
To prevent injury, disconnect all cables from the
Warning:
ValueLoader before removing the ValueLoader
cover. Keep fingers away from the ValueLoader
fan.
Remove the ValueLoader from its rack slot, if applicable, and
3
place it on a table or other flat work surface.
If the ValueLoader is a rackmounted, remove the front cover
4
screws that secure the mounting brackets from both sides of
the ValueLoader, as shown in
Remove the seven screws that secure the ValueLoader cover:
5
five on the back panel and one on each side of the
ValueLoader.
Remove the top cover by lifting it from the back and easing it
6
out from under the front panel display cover.
ValueLoader LTO Tape Autoloader User Manual
figure 15.
