3. Locate an available 5¼-inch drive bay and remove the front cover from the drive bay as
described in the server's or workstation's manuals.
4. Slide your DLT-VS80 Internal Drive into the open drive bay.

Figure 2-9: Install Drive in an Open Drive Bay: Tower, 2U server shown

Note: Install an LVD/SE SCSI host adapter in the selected server or workstation now, if
necessary. For more information on SCSI host adapter requirements, see page 2-1.
2-14
