Barcode Reader; Scsi Requirements - Freecom VALUELOADER LTO User Manual

1

Barcode Reader

SCSI
1
Requirements
The ValueLoader is compatible with most operating systems and
environments that support the SCSI interface, but requires either
direct support from the operating system or a compatible backup
application to take full advantage of its many features.
Your ValueLoader may have come equipped with an optional
barcode reader. The barcode reader is enclosed in a plastic housing
that protrudes out of the rear panel of the ValueLoader, just above
the SCSI connectors. The barcode reader automatically scans each
cartridge in the carousel upon power up, after a reset, or when a
re-inventory command is issued. (See
Cartridges on page 33 for instructions.) Beyond that, there is no
user interface with the barcode reader via the front panel operator
controls or LCD display. The information from each label is stored
in memory and available through SCSI to the computer's
operating system or backup application upon request.
If you plan to utilize the barcode reader, you must adhere a
barcode label into the designated area on the front of each
cartridge. These labels must conform to ANSI/AIM BC1-1995,
Uniform Symbology Specification Code 39. To obtain additional
barcode labels, refer to our Web site.
The ValueLoader incorporates a wide SCSI-2, LVD SCSI bus, but
may also be attached to a single-ended (SE) SCSI bus. Make sure
your SCSI host adapter or controller supports these standards. If
you connect the ValueLoader to an SE SCSI bus or if there are SE
devices attached to the same SCSI bus, the ValueLoader's
performance is limited to the maximum data transfer speed and
maximum cable lengths of the SE bus. The ValueLoader is NOT
compatible with a standard differential (Diff) or high-voltage
differential (HVD) SCSI bus. The ValueLoader is compatible with a
narrow (50-pin) SCSI bus using a customer-supplied 68-pin to 50-
pin adapter that terminates the unused 18 pins. These adapters are
sometimes labeled high-byte termination.
ValueLoader LTO Tape Autoloader User Manual
Installing the ValueLoader
Understanding ValueLoader Features
Creating an Inventory of
3
