Installing the ValueLoader into a Rack

Figure 5 Installing
Mounting Brackets
(Left Side Shown)
The ValueLoader fits all standard 19-inch racks, taking up 2U of
space. To install the ValueLoader into a rack, you need to install
the mounting brackets on both sides of the ValueLoader and the
rails in the selected rack location.
To install the ValueLoader, follow these steps:
Use a screwdriver or Torx T10 to remove the two screws near
1
the front on each side of the ValueLoader.
Using the screws you removed in
2
bracket from the rack kit to each side of the ValueLoader, as
shown in figure
ValueLoader LTO Tape Autoloader User Manual

Installing the ValueLoader into a Rack

step
5.
Installing the ValueLoader
1, secure one mounting
1
11
