Checking Cooling Conditions

This section describes the cooling conditions for the SPARC M10 systems. Note the
following conditions when installing the system:
The air conditioning facilities for the room are sufficient to meet the cooling
■
conditions of the entire system
The air conditioning facilities have control functions for preventing excessive
■
temperature changes
Table 2-7
Table 2-7 Cooling conditions
Configuration Input voltage
SPARC M10-1 100 to 120 VAC
200 to 240 VAC
PCI expansion 100 to 120 VAC
unit
200 to 240 VAC
The SPARC M10 systems are designed to function in an environment with natural
convection airflow.
The following requirements must be followed to meet the environmental specifications.
Ensuring sufficient airflow for the entire system
■
Each chassis is equipped with a cooling function for front-to-rear cooling. Each
chassis has air vents on the front. Exhaust is expelled from the rear of each chassis.
The SPARC M10 systems use internal fans whose airflow reaches the maximum
exhaust airflow shown in
Ensuring that temperature at the intake part of each chassis does not exceed the
■
limit value
Fujitsu M10-1/SPARC M10-1 Installation Guide ･ March 2019
24
CPU type
SPARC64 X
SPARC64 X+
SPARC64 X
SPARC64 X+
lists the cooling conditions for each chassis.
CPU type
SPARC64 X
SPARC64 X+
SPARC64 X
SPARC64 X+
-
-
Table 2-7
CPU configuration
In operation
1 CPUs 6.8 B
1 CPUs 7.4 B
1 CPUs 50 dB
1 CPUs 58 dB
Maximum heat dissipation
2,900 kJ/hr (2,750 BTU/hr)
3,060 kJ/hr (2,900 BTU/hr)
2,820 kJ/hr (2,670 BTU/hr)
2,970 kJ/hr (2,810 BTU/hr)
1,005 kJ/hr (953 BTU/hr)
972 kJ/hr (921 BTU/hr)
under normal operating conditions.
When idle
6.8 B
7.4 B
50 dB
58 dB
Maximum exhaust
airflow
3
2.2 m /min
3
4.5 m /min
