3.2.2 Confirming the delivered components of the PCI
expansion unit
This section describes the confirmation of delivered components of the PCI
expansion unit.
1.
Confirm the delivered components by referring to the List of Attachments that
comes with the PCI expansion unit.
Table 3-3
may change without notice.
Table 3-3 Reference: List of accessories for the PCI expansion unit
Name
PCI expansion unit
Power cord
Core
Rack mount kit
Cable support
Link cable (optical, 10 m)
Link cable (electrical, 3 m)
Management cable
Link card
*1 The power cord is ordered separately (required option), so it may not come with the product.
*2 If ordered at the same time as the SPARC M10-1, the cable is supplied with the SPARC M10-1.
*3 If ordered at the same time as the SPARC M10-1, the card is shipped mounted in the SPARC M10-1.
2.
Confirm that the PCIe cassette lever is locked at the bottom.
3.3

Confirming the Rack

Confirm that the rack is in accordance with the rack specifications described in
Confirming Rack
Warning - Be sure to take the toppling prevention measures for racks with the
SPARC M10-1 mounted. Pulling out the chassis from a rack without toppling
prevention measures may cause the rack to topple over.
below is a list of accessories for the PCI expansion unit. The accessories
Quantity Remarks
1
2 For 100 VAC or 200 VAC (*1)
2 Used when attached to power cord
1 set
1 set
2 Either of two types of cables is selected (*2)
1 (*2)
1 Card for mounting in the SPARC M10-1 chassis (*3)
Specifications" and the toppling prevention measures are taken.
Chapter 3 Installing the System
"2.4
41
