23

Technical Data

Type of gearbox
Gear shift type
Gear ratio
1st gear
2nd gear
3rd gear
4th gear
5th gear
6th gear
Oil grade (all the year round)
Capacity
initial filling
oil change
End float of spring segment at input shaft
End float at 1st gear, output shaft
End float at 2nd gear, output shaft
End float at 3rd/4th gears (total play)
output shaft
Selector shaft end float
Length of selector drum, fully compressed
R 1150 R
6-speed gearbox with claw-action shift and inte-
gral reaction damper for all gears
Foot-operated lever and selector drum with over-
shoot detent
3.864
3.022
2.393
1.962
1.700
1.511
Brand-name SAE 90 hypoid gear oil, API
Class GL 5
l (Imp. approx. 1.0 (1.76/1.06)
pint/US (to lower edge of filler screw)
quart)
l (Imp. approx. 0.8 (1.41/0.85)
(to lower edge of filler screw)
pint/US
quart)
mm (in) 0.4... 0.6 (0.0157...0.0236)
mm (in) 0.1... 0.33 (0.0039...0.0130)
mm (in) 0.1... 0.33 (0.0039...0.0130)
mm (in) 0.1... 0.67 (0.0039...0.0264)
mm (in) 0.1... 0.3 (0.0039...0.0118)
mm (in) 111.80... 111.90 (4.4015...4.4055)
23.3
