UT-4500 Series C- and Ku-Band Up Converters
Serial Interface Operation
Description
Set Fault Recovery:
Confirmation:
Return Status:
Confirmation:
8.7.3.9

PGM (Program Pre-select)

Use PGM to store up to 32 preset frequency and attenuation settings.
Description
Program Pre-select:
Confirmation:
8.7.3.10

DPS (Display All Pre-selects)

Use DPS to return all 32 of the programmed pre-select values.
Description
Display Pre-selects:
Confirmation:
Details
<DEV/AFR_xxx{cr} where:
xxx = ON or 0FF
>DEV/AFR_xxx{cr}{lf}]
<DEV/AFR_{cr}
>DEV/AFR_xxx{cr}{lf}]
Details
<DEV/PGM_nn_xxxxx.xxx_yy.yy{cr} where:
nn = Preset Number = 01 to 32.
xxxx.xxx = Frequency in MHz (RF
steps optional), dependent upon unit in use.
EXAMPLE: 5845 to 6425 MHz for Model UT-4505 (see Chapter 2.
SPECIFICATIONS for product-specific frequency ranges)
yy.yy = Attenuation value in dB from 00.00 to 25.00 in 0.25 dB step sizes (0.1
dB step size optional)
>DEV/PGM_nn_xxxxx.xxx_yy.yy{cr}{lf}]
Details
<DEV/DPS_{cr}
>DEV/DPS_{cr}
P01 xxxxx.xxx yy.yy{cr}
to
P32 xxxxx.xxx yy.yy{cr}{lf}] where:
xxxxx.xxx = Frequency
yy.yy = Attenuation
Note: Only programmed pre-select numbers are returned. If no pre-select(s)
is programmed, "No Pre-Selects Programmed" is returned.
8–23
MN/UT4500.IOM
to RF ) in 125 kHz steps (1 kHz
LOW HIGH
Revision 3
