Controls, Connections and Setup Procedures
6.2.4
6.3
Chapter 1 / 24
System Check
Precondition
The destinations, i.e. Processing Stations, intended for the digitizer, have to
be put into operation and must be obtainable via Ethernet.
System Check
1. Check whether the Processing Station(s) is/are obtainable.
Service menu:
<Checks>
<Check destinations>
2. Send a test image to the Processing Station(s).
Key operator menu:
<Send test image>.
End of System Check (approx. 5 min).
Backup of the machine specific Data
·
Do not use the factory backup!
·
A new backup is not compatible with older software!
Backup
1. Insert a new formatted floppy.
2. Start the service program.
3. Select:
<save on floppy>
<Machine specific data>
4. Start the backup procedure.
5. Label the floppy as follows:
S/N:
<XXX>
Date:
<date>
Software-
ACP_xxxx
version:
End of Backup (approx. 15 min).
ADC Compact Plus
(Type 5146)
DD+DIS064.02E
Edition 1, Revision 4
