Evaluation Criteria
Fine white or gray lines in fast-scan direction
Aim: No lines visible or effect revealed less than on sample
Quality less than sample: Contact Support center
NOTE: Fine white or gray lines can also appear, if there is dust on the
scanner - use the scan-brush for cleaning the scanner.
Dark lines or stripes in slowscan direction
Aim: No lines visible or effect revealed less than on sample
Quality less than sample: Check / adjust the position of the laser beam via
the fiber optics Expose a new flatfield and compare it with the sample.
Quality still less than sample: New calibration - Expose a new flatfield and
compare it with the sample.
Quality still less than sample: Contact Support center
Straight vertical lines occur frayed on the test sheet (Jitter effect)
Aim: proper straight lines without jitter
Quality less than sample:
Change optic module

Last Steps

· Dispose of all packing material. (depending on the country, by the
forwarding agent or by the hospital).
· Complete the Installation Report (enclosed to every device) for all system
components and forward it to the regional CSO Manager.
· Fill in the enclosed form "Site and System Data" and send it to MI CSO, if
not done yet.
· Hand over the ADC System to the application specialist.

Installation of other ADC System Components

For detailed information on the installation of other ADC System
Components like Processing Station or ID –Station, see:
ADC System Components, DD+DIS198.00E, Chapter 3.
