Preface
Purpose of the Documentation
This documentation provides detailed information about the WinAC Slot software
and hardware that includes the CPU 412-2 PCI and the CPU 416-2 PCI. You install
the WinAC Slot software and documentation from the installation CD.
The CPU 412-2 PCI and the CPU 416-2 PCI are the programmable logic
controllers (PLCs) for the Windows Automation Center (WinAC). A CPU 41x-2 PCI
is a card that fits in a PC in a PCI slot for 3/4-length cards. The CPU 41x-2 PCI is
part of the WinAC family of PC-based controllers. You can also use SIMATIC
products with PC-based controllers, such as WinCC flexible.
The PC-based controllers use a PROFIBUS DP network to communicate with
distributed I/O, such as an ET 200M. In addition, you can use PG/OP
communication (PROFIBUS, MPI, or Industrial Ethernet) to connect the PC-based
controllers to STEP 7 or to another computer.
Basic Knowledge Requirements
General knowledge about automation systems is needed to understand this
documentation.
In addition, the following knowledge is required:
•
Comprehensive knowledge of the S7-400
•
Comprehensive knowledge of STEP 7
Scope of Documentation
This documentation applies to the following modules:
CPU
CPU 412-2 PCI
CPU 416-2 PCI
This documentation describes all applicable modules at the time of publication. We
reserve the right to provide product information bulletins containing current
information for any new modules or modules with a new release number.
This documentation describes how the CPU 412-2 PCI and CPU 416-2 PCI differ
from the CPUs of the S7-400 family. For more information, refer to the manuals for
S7-400.
Windows Automation Center, WinAC Slot Version 4.0
Hardware Installation and Operating Manual, Edition 02/2006, A5E00273194-02
Order number
6ES7 612-2QH10-0AB4
6ES7 616-2QL10-0AB4
Product Version (or higher)
Firmware
Hardware
4.0
1
4.0
1
3
