System Indicator Lights

The LED on the front of the Pano device system provides the following information.
Indicator Light
Off or blinking red light
Steady white light
Steady blue light
Alternating blue and amber lights

Powering On and Off

The system turns on when you plug it into a power source. The system doesn't have a power button, so
you must unplug the power cable to turn it off.
You can power the device with the following:
▪ Power over Ethernet+ (PoE+) IEEE 802.3at Type 2 (Link Layer Discovery Protocol [LLDP]
negotiation is supported for switches that require it)
▪ 2.0 mm power adapter
Remember the following when powering the Pano device:
Polycom, Inc.
Feature
USB 3.0 host port
If you plug a dongle for a wireless pointing device into the USB 2.0 port and connect a
USB flash drive to the USB 3.0 port, the wireless pointing device may not function
properly.
USB 2.0 host port
If you plug a dongle for a wireless pointing device into the USB 2.0 port and connect a
USB flash drive to the USB 3.0 port, the wireless pointing device may not function
properly.
10/100/1000 Ethernet port
The device ships with this Ethernet port covered. This port is reserved for future use.
10/100/1000 Ethernet port powered with PoE+ PD
This port supports IEEE 1588 for time synchronization with devices in a room.
2.0 mm jack for optional external 54 V DC power adapter
System Status
System is disconnected, cannot initialize, or has encountered a severe
malfunction
System is initializing
System is running
System is in software update or factory restore mode
Getting Started
7
