Monitor Settings

Topics:
▪

HDMI I/O

▪ Supported Displays
▪ Configure Monitor Settings
The Pano device supports a variety of resolutions on touch-capable and non-touch monitors.
Note: The Pano device monitor must support a minimum of 1280×720 resolution.
Related Links
Access the System Web Interface
HDMI I/O
Your Pano system has HDMI I/O ports.
Your system has the following HDMI connections:
▪ Output for connecting the primary system monitor (Monitor 1)
▪ Output for connecting the secondary system monitor (Monitor 2)
▪ Input for content sharing, including audio streaming
Note the following:
▪ The system supports only HDMI-to-HDMI connections and doesn't support display conversions,
such as VGA-to-HDMI or HDMI-to-DVI cable converters.
▪ The HDMI specifications don't provide maximum cable length definitions. The requirements defined
in the specification implicitly give rise to length limitations that are based on the cable's construction.
▪ As with other Polycom devices, the HDMI ports on the Pano device meet HDMI specification
requirements. HDMI signal quality is dependent on every cable and connector in the HDMI path.
Passive HDMI extenders, female-female couplers and wall plates are potential points of failure and
signal loss.
▪ A high-quality passive cable of minimum length provides the most repeatable solution. As the power
level of HDMI output devices can vary greatly, keep the distance from the HDMI source to the Pano
input as short as possible.
Polycom recommends working with your A/V integrator or partner who understands the unique
requirements in your environment.
Polycom claims no responsibility or liability for the quality, performance, or reliability of third-party HDMI
cables, HDMI splitters, or HDMI USB adapters. Contact your Polycom distributor or representative to
order parts that meet the appropriate manufacturing tolerances, quality, and performance parameters for
your deployment.
