10. Click Add to apply the change to the device's running-config file.
11. Select the Save link at the bottom of the panel. Select Yes when prompted to save the configuration change
to the startup-config file on the device's flash memory.
Displaying the SNMP Community Strings
To display the SNMP community strings, use one of the following methods.
USING THE CLI
To display the configured community strings, enter the following command at any CLI level:
ProCurveRS(config)# show snmp server
Syntax: show snmp server
See the Command Line Interface Reference for ProCurve 9300/9400 Series Routing Switches for an example of
the information displayed by the command.
NOTE: If display of the strings is encrypted, the strings are not displayed. Encryption is enabled by default.
USING THE WEB MANAGEMENT INTERFACE
1. Log on to the device using a valid user name and password for read-write access.
2. Select the Management link from the System configuration panel to display the Management configuration
panel.
3. Select the Community String link to display the SNMP Community String panel, as shown in the following
example.
Using the User-Based Security Model
SNMP version 3 (RFC 2570 through 2575) introduces a User-Based Security model (RFC 2574) for authentication
and privacy services.
SNMP version 1 and version 2 use community strings to authenticate SNMP access to management modules.
This method can still be used for authentication. In SNMP version 3, the User-Based Security model of SNMP can
be used to secure against the following threats:
• Modification of information
• Masquerading the identity of an authorized entity
