MBT-5000 L-Band Up/Down Converter System
Front Panel Operation
Serial Config: Address
Remote Address: 0001
The valid range of addresses is from 1 to 9997. Use the ◄ ► arrow keys to select the digit to
edit, and then use the ▼▲arrow keys to change the value of that digit. Press ENTER when
done.
Serial Config: Baudrate
Local M&C Bus Baud Rate:
19200 Baud
To set the baud rate of the remote M&C bus connection between the unit and the user PC:
Use the ▲▼arrow keys to select 2400, 4800, 9600, 19200, and 38400. Press ENTER when
done.
5.2.2.1.3

Remote Control: Ethernet

Ethernet Config: Gateway
Address MAC SNMP
Use the ◄ ► arrow keys to select the parameter to configure – Gateway, Address, MAC, or
SNMP – then press ENTER.
Ethernet Config: Gateway
Ethernet IP Gateway:
192.168.001.002 (◄ ► ▲ ▼)
To edit the IP Gateway Address for the Ethernet M&C port for this unit, use the ◄ ► arrow
keys to first select the digit to edit, and then use the ▼▲ arrow keys to edit the value of
that digit. Press ENTER when done.
Ethernet Config: Address
Ether IP Address/Range:
192.168.001.002/24(◄ ►▲ ▼)
To edit the IP Address and Range for the Ethernet M&C port for this unit, use the ◄ ►
arrow keys to first select the digit to edit, and then use the ▼▲ arrow keys to edit the value
of that digit. Press ENTER when done.
(◄ ► ▲ ▼ E)
(▲ ▼ E)
The asynchronous character format is FIXED at 8 data bits, 1 stop bit, no parity
(8-N-1).
(◄ ► E)
