Appendix A. BUC-5000x/BDC-5000x MODULE
REMOVAL/INSTALLATION
A.1
Overview
This appendix illustrates the procedure required to remove and install a BUC-5000x
Upconverter or BDC-5000x Downconverter module (Figure A-1) into any MBT-5000
L-Band Up/Down Converter System chassis.
This procedure is typical for removing or installing a module into the applicable SIDE A
or SIDE B module bay in the MBT-5000 chassis.
Figure A-1. BUC-5000x/BDC-5000x Module
A–1
