MBT-5000 L-Band Up/Down Converter System
Serial-based Remote Product Management
7.3.1
MBT-5000 Base Unit Remote Commands and Queries
Command
Arguments for
Parameter
(Instruction
Command or
Type
Code and
Response to
Qualifier)
Auto Fault
AFR=
1 byte,
Recovery
Clear All Stored
CAE=
None
Events
Circuit
CID=
24 bytes,
Identification
Set RTC (Real-
DAY=
6 bytes
Time-Clock)
Date
(Note that all arguments are ASCII numeric codes between 48 and 57)
Query
Command or Query.
BUC/BDC output is automatically muted in event of detected fault. If auto fault recovery is
enabled, it causes output to return to pre-fault mute condition if all faults are cleared.
If disabled, the output remains muted even if all faults are cleared.
Clearing of fault condition will not cause a switchover in a redundant system unless the currently
online unit is faulted; in which case, the newly unfaulted unit is brought online.
Default Value: 1
Example: <1/AFR=1'cr'
>0001/AFR='cr''lf'
Command only.
Instructs unit to clear all Stored Events. This command takes no arguments.
Example: <1/CAE='cr'
>0001/CAE='cr''lf'
Command or Query.
Sets or queries the user-defined Circuit ID string, which is a fixed length of 24 characters.
Default value: ------------------------
Valid characters include:
Space ( ) * + – . / 0 9 and A thru Z
Command or Query.
A command in the form ddmmyy, where:
dd = day of the month (between 01 and 31);
mm = month of the year (between 01 and 12); and
yy = year (between 00 and 99; i.e., 2000 to 2099)
Example: <1/DAY=240403'cr'
>0001/DAY='cr''lf'
(date = April 24, 2003):
Description of Arguments
7–9
MN-MBT5000
Revision 4
Response to
Query
Response to query
Command
(Instruction
(Target to
Code and
Controller)
Qualifier)
AFR =
AFR?
AFR=x
AFR?
AFR*
(Same format as
Command
arguments)
CAE=
N/A
N/A
CID=
CID?
CID=x...x
CID?
(See Description of
Arguments)
DAY=
DAY?
DAY=xxxxxx
DAY?
DAY*
(Same format as
Command
arguments)
(Target to
Controller)
