Mini I/O connector (CN5)
Terminal Number
1 to 3
45 to 60
32 to 34 External power
source
Internal power
source
66 to 68 External power
source
Internal power
source
HAND I/O connector (CN9)
Terminal Number
1 to 8 Hand output terminal
17 Internal power source output (+24V)
18 Internal power source output (0V)
View from the cable side
Name
+24V internal power source terminal
Signal output terminal
+24 VDC power source input
+24 VDC power source output
0 VDC power source input
0 VDC power source output
View from the cable side
Name
+24V internal power output
24 V at output
24 VDC power input
24 VDC power output
DC power input (GND)
DC power output (GND)
Meaning
24 V at output
24 VDC power output
DC power output (GND)
81
Meaning Check point
Check point
(1)
(2)
(1)
(1)
(1)
(1)
(2)
(1)
(1)
