connect VPN multicast receivers and multicast sources. When specific network criteria are met, a
switchover from the default-MDT to the data-MDT occurs to forward VPN multicast traffic to
receivers.
The process of default-MDT to data-MDT switchover is as follows:
The source-side PE device (PE 1, for example) periodically examines the forwarding rate of the
1.
VPN multicast traffic. The default-MDT switches to the data-MDT only when the following
criteria are both met:
The VPN multicast data has passed the ACL rule filtering for default-MDT to data-MDT
switchover.
The traffic rate of the VPN multicast stream has exceeded the switchover threshold and
stayed higher than the threshold for a certain length of time.
PE 1 selects a least-referenced address from the data-group address range. Then, it sends an
2.
MDT switchover message to all the other PE devices down the default-MDT. This message
contains the VPN multicast source address, the VPN multicast group address, and the
data-group address.
Each PE device that receives this message examines whether it interfaces with a VPN that has
3.
receivers of that VPN multicast stream.
If so, it joins the data-MDT rooted at PE 1. Otherwise, it caches the message and will join the
data-MDT when it has attached receivers.
After sending the MDT switchover message, PE 1 waits a certain length of time (known as the
4.
data-delay period). Then, it starts using the default-group address to encapsulate the VPN
multicast data. The multicast data is then forwarded down the data-MDT.
After the multicast traffic is switched from the default-MDT to the data-MDT, PE 1 continues
5.
sending MDT switchover messages periodically. Subsequent PE devices with attached
receivers can then join the data-MDT. When a downstream PE device no longer has active
receivers attached to it, it leaves the data-MDT.
For a given VPN instance, the default-MDT and the data-MDT are both forwarding tunnels in the
same MD. A default-MDT is uniquely identified by a default-group address, and a data-MDT is
uniquely identified by a data-group address. Each default-group is uniquely associated with a
data-group address range.
Backward switching from data-MDT to default-MDT
After the VPN multicast traffic is switched to the data-MDT, the multicast traffic conditions might
change and no longer meet the switchover criterion. In this case, PE 1, as in the preceding example,
initiates a backward MDT switchover process when any of the following criteria are met:
•
The traffic rate of the VPN multicast data has dropped below the switchover threshold. In
addition, the traffic rate has stayed lower than the threshold for a certain length of time (known
as the data-holddown period).
•
The associated data-group address range is changed, and the data-group address for
encapsulating the VPN multicast data is out of the new address range.
•
The ACL rule for controlling the switchover from the default-MDT to the data-MDT has changed,
and the VPN multicast data fails to pass the new ACL rule.

Inter-AS MD VPN

In an inter-AS VPN networking scenario, VPN sites are located in multiple ASs. These sites must be
interconnected. Inter-AS VPN provides the following solutions:
•
VRF-to-VRF connections between ASBRs—This solution is also called inter-AS option A.
•
EBGP redistribution of labeled VPN-IPv4 routes between ASBRs—ASBRs advertise
VPN-IPv4 routes to each other through MP-EBGP. This solution is also called inter-AS option B.
The switch does no support inter-AS option B.
