Port Policies Configuration
Every port may advertise a unique set of network policies or different attributes for the same network policies, based on the
authenticated user identity or port configuration.
Object
• Port
• Policy ID
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.

4.14.4 LLDP-MED Neighbor

This page provides a status overview for all LLDP-MED neighbors. The displayed table contains a row for each port on which an
LLDP neighbor is detected. The LLDP-MED Neighbor Information screen in
following information:
The page includes the following fields:
Fast start repeat count
Object
• Port
• Device Type
Description
The port number for which the configuration applies.
The set of policies that shall apply for a given port. The set of policies is selected
by checkmarking the checkboxes that corresponds to the policies
Figure 4-14-3: LLDP-MED Neighbor Information Page Screenshot
Description
The port on which the LLDP frame was received.
LLDP-MED Devices are comprised of two primary Device Types: Network
Connectivity Devices and Endpoint Devices.
LLDP-MED Network Connectivity Device Definition
User's Manual of GS-5220 Ultra PoE & PoE+ Series
Figure 4-14-3
316
appears. The columns hold the
