4.15.3 Remote IP Ping Test
This page allows you to issue ICMP PING packets to troubleshoot IP connectivity issues on special port.
After you press "Test", 5 ICMP packets are transmitted, and the sequence number and roundtrip time are displayed upon
reception of a reply. The page refreshes automatically until responses to all packets are received, or until a timeout occurs. The
ICMP Ping screen in
Figure 4-15-3
The page includes the following fields:
Object
• Port
•
Remote IP Address
•
Ping Size
•
Result
Buttons
: Click to apply changes
:
Click to undo any changes made locally and revert to previously saved values.
: Clears the IP Address and the result of ping value.
User's Manual of GS-5220 Ultra PoE & PoE+ Series
appears.
Figure 4-15-3: Remote IP Ping Test Page Screenshot
Description
The logical port for the settings.
The destination IP Address.
The payload size of the ICMP packet. Values range from 8 bytes to 1400 bytes.
Display the ping result.
