The page includes the following fields:
Object
• Login(Optional)
• Port
• Status
• Device Type
• Device Name
• Manufacturer
• Model
• IP Address
• MAC Address
• Power Used [W]
• Action
Buttons
: Click to refresh the page immediately.
Auto-refresh : Check this box to refresh the page automatically. Automatic refresh occurs every 30 seconds.
: Updates the ONVIF device entries, press to the first page.
: Updates the ONVIF device entries, press to the front page.
: Updates the ONVIF device entries, press to the next page.
: Updates the ONVIF device entries, press to the final page.

4.19.3 Map Upload / Edit

This page allows the clients for uploading e-MAP, the file size can not over 151k; screen in
User's Manual of GS-5220 Ultra PoE & PoE+ Series
Description
Allows for filling one set of User name and Password.
This is the logical port number for this row.
Red: The ONVIF device is not active.
Green: The ONVIF device is active.The ONVIF Device's Type of the entry.
The ONVIF Device's Type of the entry.
The ONVIF Device's Name of the entry.
The ONVIF Device's Manufacturer of the entry.
The ONVIF Device's Model Name of the entry.
The ONVIF Device's IP Address of the entry.
The ONVIF Device's MAC address of the entry.
The Power Used shows how much power the ONVIF device currently is using.
There are three actions:
Access: Clicks for accessing into the ONVIF device's WEBUI.
Reboot: Clicks for rebooting the ONVIF device.
Delete: Clicks for deleting the ONVIF device from ONVIF Device List.
357
Figure 4-19-3 appears.
