4.9.15 QoS Statistics

This page provides statistics for the different queues for all switch ports. The QoS Statistics screen in
The page includes the following fields:
Object
•
Port
•
Q0 ~ Q7
• Rx/Tx
Buttons
: Click to refresh the page immediately.
: Clears the counters for all ports.
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.

4.9.16 Voice VLAN Configuration

The Voice VLAN feature enables voice traffic forwarding on the Voice VLAN, then the switch can classify and schedule network
traffic. It is recommended that there be two VLANs on a port - one for voice, one for data.
Before connecting the IP device to the switch, the IP phone should configure the voice VLAN ID correctly. It should be
configured through its own GUI. The Voice VLAN Configuration screen in
User's Manual of GS-5220 Ultra PoE & PoE+ Series
Figure 4-9-17: Queuing Counters Page Screenshot
Description
The logical port for the settings contained in the same row.
There are 8 QoS queues per port. Q0 is the lowest priority queue.
The number of received and transmitted packets per queue.
218
Figure 4-9-18 appears.
Figure 4-9-17 appears.
