4.17 Loop Protection

This chapter describes enabling loop protection function that provides loop protection to prevent broadcast loops in Managed
Switch.
4.17.1 Configuration
This page allows the user to inspect the current Loop Protection configurations, and possibly change them as well as screen in
Figure 4-17-1 appears.
The page includes the following fields:
General Settings
Object
•
Enable Loop
Protection
Figure 4-17-1: Loop Protection Configuration Page Screenshot
Description
Controls whether loop protection is enabled (as a whole).
User's Manual of GS-5220 Ultra PoE & PoE+ Series
342
