The page includes the following fields:
Object
• DSCP
• Trust
• QoS Class
•
DPL

4.9.9 DSCP Translation

This page allows you to configure the basic QoS DSCP Translation settings for all switches. DSCP translation can be done in
Ingress or Egress. The DSCP Translation screen in
User's Manual of GS-5220 Ultra PoE & PoE+ Series
Description
Maximum number of supported DSCP values are 64.
Controls whether a specific DSCP value is trusted. Only frames with trusted
DSCP values are mapped to a specific QoS class and Drop Precedence Level.
Frames with untrusted DSCP values are treated as a non-IP frame.
QoS Class value can be any of (0-7)
Drop Precedence Level (0-1)
Figure 4-9-10
Figure 4-9-10: DSCP Translation Page Screenshot
207
appears.
