4.18.5 RMON History Configuration

Configure RMON History table on this page. The entry index key is ID; screen in
The page includes the following fields:
Object
• Delete
• ID
• Data Source
• Interval
• Buckets
• Buckets Granted
Buttons
: Click to add a new community entry.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
Figure 4-18-6: RMON History Configuration Page Screenshot
Description
Check to delete the entry. It will be deleted during the next save.
Indicates the index of the entry. The range is from 1 to 65535.
Indicates the port ID which wants to be monitored.
Indicates the interval in seconds for sampling the history statistics data. The
range is from 1 to 3600, default value is 1800 seconds.
Indicates the maximum data entries associated this History control entry stored in
RMON. The range is from 1 to 3600, default value is 50.
The number of data will be saved in the RMON.
User's Manual of GS-5220 Ultra PoE & PoE+ Series
Figure 4-18-6
350
appears.
