230 C 6: C
HAPTER ONFIGURING
Adding a New ACE to
a Configured ACL

Mapping an ACL

WX S P
YSTEM ARAMETERS
Table 17 ICMP Messages and Codes (continued)
ICMP Message (Type Number)
Timestamp (13)
Timestamp Reply (14)
Information Request (15)
Information Reply (16)
To add a new ACE to a configured ACL:
1 Access the ACL table:
a Select the Configuration tool bar option.
b In the Organizer panel, click the plus sign next to the WX switch.
c Click the plus sign next to System.
d Select ACLs.
2 Select any ACE in the ACL to which you want to add the new ACE.
3 In the Task List panel, select Add Rules.
4 Go to step 3.
An ACL does not take effect until you map it to a user or an interface.
You can map ACLs to ports (or port groups), VLANs, or virtual ports. You
cannot map an ACL to a MAP port or a wired authentication port.
You also can map ACLs to user, by configuring the filter.in and filter.out
user attributes. User-based ACLs are more specific than ACLs applied to
interfaces and are therefore processed first. (See "Authorization
Attributes" on page 295.)
1 Access the ACL table:
a Select the Configuration tool bar option.
b In the Organizer panel, click the plus sign next to the WX switch.
c Click the plus sign next to System.
d Select ACLs.
2 Select any ACE in the ACL you want to map.
3 In the Task List panel, select ACL Mappings.
Code (Number)
None
None
None
None
