Page 13: About The Documentation
® To obtain the most current version of all Juniper Networks technical documentation, see the product documentation page on the Juniper Networks website at http://www.juniper.net/techpubs/ If the information in the latest release notes differs from the information in the documentation, follow the product Release Notes.
Page 14: Table 1: Notice Icons
ACX1000 and ACX1100 Universal Access Router Table 1: Notice Icons Icon Meaning Description Informational note Indicates important features or instructions. Caution Indicates a situation that might result in loss of data or hardware damage. Warning Alerts you to the risk of personal injury or death.
Page 15: Documentation Feedback
We encourage you to provide feedback, comments, and suggestions so that we can improve the documentation. You can provide feedback by using either of the following methods: Online feedback rating system—On any page of the Juniper Networks TechLibrary site , simply click the stars to rate the content, http://www.juniper.net/techpubs/index.html and use the pop-up form to provide us with information about your experience.
Page 16: Requesting Technical Support
7 days a week, 365 days a year. Self-Help Online Tools and Resources For quick and easy problem resolution, Juniper Networks has designed an online self-service portal called the Customer Support Center (CSC) that provides you with the following features: Find CSC offerings: http://www.juniper.net/customers/support/...
Page 17 About the Documentation For international or direct-dial options in countries without toll-free numbers, see http://www.juniper.net/support/requesting-support.html Copyright © 2017, Juniper Networks, Inc. xvii...
Page 19: Overview
PART 1 Overview System Overview and Architecture on page 3 Chassis Components and Descriptions on page 27 Cooling System and Airflow Components and Descriptions on page 39 Power System Components and Descriptions on page 41 Copyright © 2017, Juniper Networks, Inc.
Page 21: System Overview And Architecture
System Overview and Architecture ACX1000 and ACX1100 Universal Access Router Overview on page 3 ACX1000 and ACX1100 Routers Hardware and CLI Terminology Mapping on page 5 Packet Flow on ACX Series Routers on page 8 Protocols and Applications Supported by ACX Series Routers on page 9...
Page 22: Acx1000 Router Description
300-mm deep (or larger) enclosed cabinets, 19-in. equipment racks, or telco open-frame racks. ACX1000 Router Description The ACX1000 routers contain eight T1/E1 ports and twelve Gigabit Ethernet ports, eight of which are RJ-45 ports. The ports labeled COMBO PORTS provide an additional four RJ-45 ports or four Gigabit Ethernet SFP ports.
Page 23: Acx1000 And Acx1100 Routers Hardware And Cli Terminology Mapping
Figure 3: Front View of the ACX1100 Router Figure 4: Rear View of the ACX1100 Router Related ACX1000 and ACX1100 Routers Hardware and CLI Terminology Mapping on page 5 Documentation LEDs on ACX1000 and ACX1100 Routers on page 35 ACX1000 and ACX1100 Routers Hardware and CLI Terminology Mapping...
Page 24: Acx1100 Routers Hardware And Cli Terminology Mapping
ACX1000 and ACX1100 Universal Access Router Table 3: CLI Equivalents of Terms Used in Documentation for ACX1000 Router (continued) Hardware Item (as Value (as displayed Description (as displayed in the in the CLI) displayed in the CLI) CLI) Item in Documentation...
Page 25: Figure 6: Acx1100 Interface Port Mapping
3 4x 1GE (SFP) Xcvr (n) Abbreviated name of the n is a value Optical transceivers “Uplink Ports on ACX1000 and transceiver equivalent to the ACX1100 Routers” on page 32 number of the port in which the transceiver is installed.
Page 26: Packet Flow On Acx Series Routers
ACX1000 and ACX1100 Universal Access Router Related ACX1000 and ACX1100 Universal Access Router Overview on page 3 Documentation Packet Flow on ACX Series Routers The class-of-service (CoS) architecture for ACX Series routers is in concept similar to that for MX Series routers. The general architecture for ACX Series routers is shown in...
Page 27: Protocols And Applications Supported By Acx Series Routers
Knowledge Base (KB) article KB28179 at: https://kb.juniper.net/InfoCenter/index?page=content&id=KB28179 Table 5: Protocols and Applications Supported by ACX Series Routers Protocol or Application ACX1000 ACX1100 ACX2000 ACX2100 ACX4000 ACX5048 ACX5096 ACX500 Interface and Encapsulation Types Copyright © 2017, Juniper Networks, Inc.
Page 28 ACX1000 and ACX1100 Universal Access Router Table 5: Protocols and Applications Supported by ACX Series Routers (continued) Protocol or Application ACX1000 ACX1100 ACX2000 ACX2100 ACX4000 ACX5048 ACX5096 ACX500 Ethernet interfaces—1G, 12.2 12.2R2 12.2 12.2R2 12.3x51 15.1X54 15.1X54 12.3X54 -D10 –D20 –D20...
Page 29 15.1X54 15.1X54 12.3X54 (OSPF, IS-IS) -D10 –D20 –D20 –D20 (Indoor) 12.3X54 –D25 (Outdoor) Maximum transmission unit 12.2 12.2R2 12.2 12.2R2 12.3x51 15.1X54 15.1X54 12.3X54 (MTU) 1518 -D10 –D20 –D20 –D20 (Indoor) 12.3X54 –D25 (Outdoor) Copyright © 2017, Juniper Networks, Inc.
Page 30 ACX1000 and ACX1100 Universal Access Router Table 5: Protocols and Applications Supported by ACX Series Routers (continued) Protocol or Application ACX1000 ACX1100 ACX2000 ACX2100 ACX4000 ACX5048 ACX5096 ACX500 Layer 3 VPNs 12.3R1 12.3R1 12.3R1 12.3R1 12.3x51 15.1X54 15.1X54 12.3X54 -D10 –D20...
Page 31 – – – 15.1X54 15.1X54 – –D20 –D20 Ethernet Layer 2 Ethernet in the first mile 12.2 12.2R2 12.2 12.2R2 12.3x51 15.1X54 15.1X54 12.3X54 (EFM 802.3ah) -D10 –D20 –D20 –D20 (Indoor) 12.3X54 –D25 (Outdoor) Copyright © 2017, Juniper Networks, Inc.
Page 32 ACX1000 and ACX1100 Universal Access Router Table 5: Protocols and Applications Supported by ACX Series Routers (continued) Protocol or Application ACX1000 ACX1100 ACX2000 ACX2100 ACX4000 ACX5048 ACX5096 ACX500 802.1ag connectivity fault 12.2 12.2R2 12.2 12.2R2 12.3x51 15.1X54 15.1X54 12.3X54 management (CFM) -D10 –D20...
Page 33 12.2 12.2R2 12.2 12.2R2 12.3x51 15.1X54 15.1X54 12.3X54 -D10 –D20 –D20 –D20 (Indoor) 12.3X54 –D25 (Outdoor) Priority queuing 12.2 12.2R2 12.2 12.2R2 12.3x51 15.1X54 15.1X54 12.3X54 -D10 –D20 –D20 –D20 (Indoor) 12.3X54 –D25 (Outdoor) Copyright © 2017, Juniper Networks, Inc.
Page 34 ACX1000 and ACX1100 Universal Access Router Table 5: Protocols and Applications Supported by ACX Series Routers (continued) Protocol or Application ACX1000 ACX1100 ACX2000 ACX2100 ACX4000 ACX5048 ACX5096 ACX500 Rate control 12.2 12.2R2 12.2 12.2R2 12.3x51 15.1X54 15.1X54 12.3X54 -D10 –D20 –D20...
Page 35 Timing Timing-1588-v2, 12.2 12.2R2 12.2 12.2R2 12.3x51 – – 12.3X54 1588-2008–backup clock -D10 –D20 (Indoor) 12.3X54 –D25 (Outdoor) Synchronous Ethernet 12.2 12.2R2 12.2 12.2R2 12.3x51 – – 12.3X54 -D10 –D20 (Indoor) 12.3X54 –D25 (Outdoor) Copyright © 2017, Juniper Networks, Inc.
Page 36 ACX1000 and ACX1100 Universal Access Router Table 5: Protocols and Applications Supported by ACX Series Routers (continued) Protocol or Application ACX1000 ACX1100 ACX2000 ACX2100 ACX4000 ACX5048 ACX5096 ACX500 Building-integrated timing 12.2 12.2R2 12.2 12.2R2 12.3x51 – – 12.3X54 supply (BITS) -D10 –D20...
Page 37 12.2 12.2R2 12.3x51 15.1X54 15.1X54 12.3X54 -D10 –D20 –D20 –D20 (Indoor) 12.3X54 –D25 (Outdoor) TFTP for software 12.2 12.2R2 12.2 12.2R2 12.3x51 15.1X54 15.1X54 12.3X54 downloads -D10 –D20 –D20 –D20 (Indoor) 12.3X54 –D25 (Outdoor) Copyright © 2017, Juniper Networks, Inc.
Page 38 ACX1000 and ACX1100 Universal Access Router Table 5: Protocols and Applications Supported by ACX Series Routers (continued) Protocol or Application ACX1000 ACX1100 ACX2000 ACX2100 ACX4000 ACX5048 ACX5096 ACX500 Port mirroring (local port 12.2 12.2R2 12.2 12.2R2 12.3x51 – – 12.3X54...
Page 39 12.2R2 12.3x51 15.1X54 15.1X54 12.3X54 prevention -D10 –D20 –D20 –D20 (Indoor) 12.3X54 –D25 (Outdoor) High Availability MPLS FRR 12.2 12.2R2 12.2 12.2R2 12.3x51 15.1X54 15.1X54 12.3X54 -D10 –D20 –D20 –D20 (Indoor) 12.3X54 –D25 (Outdoor) Copyright © 2017, Juniper Networks, Inc.
Page 40 ACX1000 and ACX1100 Universal Access Router Table 5: Protocols and Applications Supported by ACX Series Routers (continued) Protocol or Application ACX1000 ACX1100 ACX2000 ACX2100 ACX4000 ACX5048 ACX5096 ACX500 12.2 12.2R2 12.2 12.2R2 12.3x51 15.1X54 15.1X54 12.3X54 -D10 –D20 –D20 –D20 (Indoor) 12.3X54...
Page 41 – – 12.3X54 ATM (IMA) -D10 –D20 (Indoor) 12.3X54 –D25 (Outdoor) ATM Encapsulation AAL5 SDU (n-to-1 cell 12.2 12.2R2 12.2 12.2R2 12.3x51 – – 12.3X54 relay) -D10 –D20 (Indoor) 12.3X54 –D25 (Outdoor) ATM Queuing Copyright © 2017, Juniper Networks, Inc.
Page 42 ACX1000 and ACX1100 Universal Access Router Table 5: Protocols and Applications Supported by ACX Series Routers (continued) Protocol or Application ACX1000 ACX1100 ACX2000 ACX2100 ACX4000 ACX5048 ACX5096 ACX500 ATM service categories 12.2 12.2R2 12.2 12.2R2 12.3x51 – – 12.3X54 (CBR, nrt-VBR, UBR) to the -D10 –D20...
Page 43 ACX1100 ACX2000 ACX2100 ACX4000 ACX5048 ACX5096 ACX500 Juniper Networks 12.2 12.2R2 12.2 12.2R2 12.3x51 15.1X54 15.1X54 12.3X54 enterprise-specific MIBs -D10 –D20 –D20 –D20 (Indoor) 12.3X54 –D25 (Outdoor) Related ACX Series Universal Access Routers Documentation Copyright © 2017, Juniper Networks, Inc.
Page 45: Chassis Components And Descriptions
A DE15 alarm cable is required to connect the ACX1000 and ACX1100 router to external alarm devices. Use the gauge wire appropriate for the external device that you are connecting.
Page 46: Figure 9: Sample Output Alarm-Reporting Device
ACX1000 and ACX1100 Universal Access Router Table 6: Alarm Relay Contact Functions Contact Name Contact Name Function Contact 1 Normally Open (NO) Current is not flowing through Contact 1 and Contact 2 [REF] when operating normally. When the current flows, the closed alarm is generated.
Page 47: Clocking Ports On The Acx1000 And Acx1100 Router
Timing input when configured as Ordinary Clock (OC) or Boundary Clock (BC) Timing output when configured as BC Related External Clocking Ports Specifications on the ACX1000 and ACX1100 Router on page 65 Documentation Connecting the ACX1000 or ACX1100 Router to External Clocking Devices on page 112...
Page 48: Front Panel Of An Acx1000 Router
ACX1000 and ACX1100 Universal Access Router Front Panel of an ACX1000 Router The front panel of an ACX1000 router consists of the following components (see Figure 11 on page 30): Chassis status LED labeled DC power terminals USB port for upgrading Junos OS...
Page 49: Front Panel Of An Acx1100 Router
Chapter 2: Chassis Components and Descriptions ACX1000 and ACX1100 Routers Hardware and CLI Terminology Mapping on page 5 LEDs on ACX1000 and ACX1100 Routers on page 35 Front Panel of an ACX1100 Router The front panel of an ACX1100 router consists of the following components (see...
Page 50: Uplink Ports On Acx1000 And Acx1100 Routers
Related ACX1000 and ACX1100 Universal Access Router Overview on page 3 Documentation ACX1000 and ACX1100 Routers Hardware and CLI Terminology Mapping on page 5 LEDs on ACX1000 and ACX1100 Routers on page 35 Uplink Ports on ACX1000 and ACX1100 Routers Unless otherwise specified, the information about uplink ports applies to both ACX1000 and ACX1100 routers.
Page 51: Gigabit Ethernet Rj-45 Ports
E1 framing: through ce1-0/0/0 ce1-0/0/7 Gigabit Ethernet RJ-45 Ports Each ACX1000 and ACX1100 router has twelve Gigabit Ethernet RJ-45 ports. Table 8 on page 33 describes the ports in more detail. Table 8: RJ-45 Port Features Feature Description Supported standards...
Page 52: Gigabit Ethernet Sfp Ports
ACX1100: through ge-0/1/0 ge-0/1/3 Related ACX1000 and ACX1100 Universal Access Router Overview on page 3 Documentation Front Panel of an ACX1000 Router on page 30 LEDs on ACX1000 and ACX1100 Routers on page 35 Copyright © 2017, Juniper Networks, Inc.
Page 53: Leds On Acx1000 And Acx1100 Routers
Router has reported an alarm. On steadily Router has failed. T1/E1 Port LEDs The front panel of the ACX1000 router has eight T1/E1 ports, each with one pair of port LEDs. Table 11 on page 35 describes the LEDs in more detail.
Page 54: Ethernet Port Leds
ACX1000 and ACX1100 Universal Access Router Ethernet Port LEDs Each Gigabit Ethernet RJ-45 port on the front panel of the router has one pair of port LEDs. Table 12 on page 36 describes the LEDs in more detail. Table 12: Ethernet Port LEDs...
Page 55 The port is receiving data. – The port is not receiving data. Related Troubleshooting Resources for ACX1000 and ACX1100 Routers on page 137 Documentation Front Panel of an ACX1000 Router on page 30 Uplink Ports on ACX1000 and ACX1100 Routers on page 32...
Page 57: Cooling System And Airflow Components And Descriptions
Cooling System and Airflow Components and Descriptions Cooling System and Airflow in an ACX1000 and ACX1100 Router on page 39 Cooling System and Airflow in an ACX1000 and ACX1100 Router The router does not contain fans and is passively cooled by the heatsinks (see Figure 14 on page 39).
Page 58 ACX1000 and ACX1100 Universal Access Router Clearance Requirements for Airflow and Hardware Maintenance on ACX1000 and ACX1100 Routers on page 56 ACX1000 and ACX1100 Router Environmental Specifications on page 48 Copyright © 2017, Juniper Networks, Inc.
Page 59: Power System Components And Descriptions
Maximum consumed by the router 65 W Related Connecting DC Power Cables to the ACX1000 or ACX1100 Router on page 105 Documentation ACX1000 and ACX1100 DC Power Electrical Safety Guidelines on page 187 ACX1000 and ACX1100 DC Power Specifications on page 61...
Page 61: Site Planning, Preparation, And Specifications
Preparation Overview on page 45 Rack and Cabinet Requirements on page 51 Cooling System and Airflow on page 55 Planning Power Requirements on page 57 Ports and Connectors on page 63 Transceiver and Cable Specifications on page 81 Copyright © 2017, Juniper Networks, Inc.
Page 63: Preparation Overview
CHAPTER 5 Preparation Overview Site Preparation Checklist for ACX1000 and ACX1100 Routers on page 45 General Site Guidelines for ACX Series Routers on page 46 Site Preparation Checklist for ACX1000 and ACX1100 Routers on page 47 ACX1000 and ACX1100 Router Environmental Specifications on page 48...
Page 64: General Site Guidelines For Acx Series Routers
Plan the cable routing and management. Related Installing and Connecting an ACX1000 or ACX1100 Router Overview on page 97 Documentation General Site Guidelines for ACX Series Routers on page 46 General Site Guidelines for ACX Series Routers Efficient device operation requires proper site planning and maintenance and proper layout of the equipment, rack or cabinet (if used), and wiring closet.
Page 65: Site Preparation Checklist For Acx1000 And Acx1100 Routers
Install the device in a secure area, so that only authorized personnel can access the device. Related General Safety Warnings for Juniper Networks Devices on page 156 Documentation General Safety Guidelines for Juniper Networks Devices on page 155 Installation Safety Warnings for Juniper Networks Devices on page 164...
Page 66: Acx1000 And Acx1100 Router Environmental Specifications
Plan the cable routing and management. Related Installing and Connecting an ACX1000 or ACX1100 Router Overview on page 97 Documentation General Site Guidelines for ACX Series Routers on page 46 ACX1000 and ACX1100 Router Environmental Specifications The router must be installed in a rack or cabinet housed in a dry, clean, well-ventilated, and temperature-controlled environment.
Page 67: Table 18: Router Environmental Specifications
Install the router only in restricted areas, such as dedicated equipment rooms and equipment closets, in accordance with Articles 110-16, 110-17, and 110-18 of the National Electrical Code, ANSI/NFPA 70. Related Chassis Physical Specifications for ACX1000 and ACX1100 Routers Documentation Copyright © 2017, Juniper Networks, Inc.
Page 69: Rack And Cabinet Requirements
Clearance requirements Cabinet airflow requirements Table 19 on page 51 provides the cabinet requirements and specifications for the router. Table 19: Cabinet Requirements and Specifications for the ACX1000 and ACX1100 Router Cabinet Requirement Guidelines Cabinet size You can mount the router in a cabinet that contains a 19-in.
Page 70: Rack Requirements For Acx1000 And Acx1100 Routers
Clearance Requirements for Airflow and Hardware Maintenance on ACX1000 and ACX1100 Routers on page 56 Installing and Connecting an ACX1000 or ACX1100 Router Overview on page 97 Rack Requirements for ACX1000 and ACX1100 Routers You can mount the router on two-post racks or four-post racks.
Page 71: Table 20: Rack Requirements And Specifications For The Router
Related Cabinet Requirements for ACX1000 and ACX1100 Routers on page 51 Documentation General Site Guidelines for ACX Series Routers on page 46 Installing and Connecting an ACX1000 or ACX1100 Router Overview on page 97 Copyright © 2017, Juniper Networks, Inc.
Page 73: Cooling System And Airflow
CHAPTER 7 Cooling System and Airflow Cooling System and Airflow in an ACX1000 and ACX1100 Router on page 55 Clearance Requirements for Airflow and Hardware Maintenance on ACX1000 and ACX1100 Routers on page 56 Cooling System and Airflow in an ACX1000 and ACX1100 Router...
Page 74: Clearance Requirements For Airflow And Hardware Maintenance On Acx1000 And Acx1100 Routers
Rack Requirements for ACX1000 and ACX1100 Routers on page 52 Cabinet Requirements for ACX1000 and ACX1100 Routers on page 51 General Site Guidelines for ACX Series Routers on page 46 Installing and Connecting an ACX1000 or ACX1100 Router Overview on page 97 Copyright © 2017, Juniper Networks, Inc.
Page 75: Planning Power Requirements
Two threaded holes are provided on the front of the router chassis for connecting the router to earth ground. The grounding points fit 0.5-inch-long SAE 10-32 screws (American). The grounding points are spaced at 0.625-in. (15.86-mm) centers. Figure 17: Grounding Points on the ACX1000 and ACX1100 Router T1/E1 ACX1000...
Page 76: Grounding Cable Lug Specifications
ACX1000 and ACX1100 Universal Access Router NOTE: All bare grounding connection points to the router must be cleaned and coated with an antioxidant solution before grounding the router. NOTE: All surfaces on the router that are unplated must be brought to a bright finish and treated with an antioxidant solution before connecting the router.
Page 77: Grounding Cable Specifications
(4.11 mm ), minimum 90°C wire, or as required by the local code. Related Connecting the ACX1000 or ACX1100 Router to Earth Ground on page 103 Documentation Preventing Electrostatic Discharge Damage to an ACX1000 or ACX1100 Router on page 158...
Page 78: Table 22: Ac Power Cord Specifications
ACX1000 and ACX1100 Universal Access Router into the AC appliance inlet coupler. The plug at the male end of the power cord fits into the power source receptacle that is standard for your geographic location. Table 22 on page 60 provides specifications on the AC power cord provided for each country or region.
Page 79: Acx1000 And Acx1100 Dc Power Specifications
Documentation ACX1000 and ACX1100 DC Power Specifications The power supplies in ACX1000 and ACX1100 routers are built in along the front left panel of the chassis with DC power terminals to connect power to the router. The power supplies are labeled When the ACX1100 router are operating normally and both power supplies are switched on, load sharing between them occurs automatically.
Page 80 Related ACX1000 and ACX1100 DC Power Electrical Safety Guidelines on page 187 Documentation DC Power Electrical Safety Warnings for Juniper Networks Devices on page 188 Copyright © 2017, Juniper Networks, Inc.
Page 81: Ports And Connectors
Ports and Connectors Alarm Contact Port Pinouts for ACX1000 and ACX1100 Routers on page 63 External Clocking Ports Specifications on the ACX1000 and ACX1100 Router on page 65 Console/Auxiliary Port Connector Pinout on ACX Series Routers on page 65 Management Port Connector Pinout Information for ACX Series Routers on page 66...
Page 82 ACX1000 and ACX1100 Universal Access Router Overview on page 3 Documentation Front Panel of an ACX1000 Router on page 30 LEDs on ACX1000 and ACX1100 Routers on page 35 Alarm Contact Port on ACX1000 and ACX1100 Routers on page 27 Copyright © 2017, Juniper Networks, Inc.
Page 83: External Clocking Ports Specifications On The Acx1000 And Acx1100 Router
Chapter 9: Ports and Connectors External Clocking Ports Specifications on the ACX1000 and ACX1100 Router The external clocking port on the ACX1000 and ACX1100 router contains four SMB connectors that support 10 MHz GPS and 1 pulse-per-second (PPS) signals. These signals are internally isolated and have surge protection.
Page 84: Management Port Connector Pinout Information For Acx Series Routers
Console/Auxiliary Port Connector Pinout on ACX Series Routers on page 65 Documentation USB Port Specifications for an ACX Series Router The following Juniper Networks USB flash drives have been tested and are officially supported for the USB port on all ACX Series routers: RE-USB-1G-S...
Page 85: Network Cable And Transceiver Overview For Acx Series, M Series, And Mx Series Routers
Network Cable and Transceiver Overview for ACX Series, M Series, and MX Series Routers Juniper Networks devices support a variety of fixed and pluggable transceivers and network cable, including multimode and single-mode fiber-optic cable. For a list of transceivers, see “Supported Network Interface Standards by Transceiver for ACX Series,...
Page 86: Supported Network Interface Standards By Transceiver For Acx Series, M Series, Mx Series, And T Series Routers
(JTAC) can help you diagnose the source of the problem. Your JTAC engineer might recommend that you check the third-party optic or cable and potentially replace it with an equivalent Juniper Networks optic or cable that is qualified for the device.
Page 87: Table 27: Supported Ethernet Standards
Fast Ethernet and Gigabit Ethernet Bidirectional SFP Optical Interface Specifications SFP-GE10KT13R14 1000BASE-BX Fast Ethernet and Gigabit Ethernet Bidirectional SFP Optical Interface Specifications SFP-GE10KT13R15 1000BASE-BX Fast Ethernet and Gigabit Ethernet Bidirectional SFP Optical Interface Specifications Copyright © 2017, Juniper Networks, Inc.
Page 88 ACX1000 and ACX1100 Universal Access Router Table 27: Supported Ethernet Standards (continued) Transceiver Monitoring Model Number Type Connector Available Standard Specifications SFP-GE10KT14R13 1000BASE-BX Fast Ethernet and Gigabit Ethernet Bidirectional SFP Optical Interface Specifications SFP-GE10KT15R13 1000BASE-BX Fast Ethernet and Gigabit Ethernet...
Page 89 10GBASE-Z 10-Gigabit Ethernet 10GBASE Optical Interface Specifications SFPP-10GE-ER SFP+ 10GBASE-ER 10-Gigabit Ethernet 10GBASE Optical Interface Specifications SFPP-10GE-LR SFP+ 10GBASE-LR 10-Gigabit Ethernet 10GBASE Optical Interface Specifications SFPP-10GE-LRM SFP+ 10GBASE-LRM 10-Gigabit Ethernet 10GBASE Optical Interface Specifications Copyright © 2017, Juniper Networks, Inc.
Page 90 ACX1000 and ACX1100 Universal Access Router Table 27: Supported Ethernet Standards (continued) Transceiver Monitoring Model Number Type Connector Available Standard Specifications SFPP-10GE-SR SFP+ 10GBASE-SR 10-Gigabit Ethernet 10GBASE Optical Interface Specifications SFPP-10GE-ZR SFP+ 10GBASE-Z 10-Gigabit Ethernet 10GBASE Optical Interface Specifications XENPAK-1XGE-ER...
Page 91 Interface Specifications CFP-100GBASE-LR4 100GBASE-LR4 100-Gigabit Ethernet 100GBASE-R Optical Interface Specifications CFP-GEN2-100GBASE-LR4 100GBASE-LR4 100-Gigabit Ethernet 100GBASE-R Optical Interface Specifications CFP-100GBASE-SR10 24-fiber 100GBASE-SR10 100-Gigabit Ethernet 100GBASE-R Optical NOTE: Interface Specifications Optical power monitoring is not supported. Copyright © 2017, Juniper Networks, Inc.
Page 92 ACX1000 and ACX1100 Universal Access Router Table 27: Supported Ethernet Standards (continued) Transceiver Monitoring Model Number Type Connector Available Standard Specifications CFP-100GBASE-ZR None See the Juniper Networks specification in the 100-Gigabit Ethernet 100GBASE-R Optical Interface Specifications. CFP2-100GBASE-LR4 CFP2 100GBASE-LR4 See the Juniper...
Page 93: Table 28: Supported Sonet Standards
SONET/SDH OC48/STM16 Long OC48/STM16 Optical Reach (LR-2) Interface Specifications SFP-1OC48-SR SONET/SDH SONET/SDH OC48/STM16 Short OC48/STM16 Optical Reach (SR-1) Interface Specifications SONET OC192/STM64 Specifications XFP-10G-E-OC192-IR2 SONET/SDH SONET/SDH OC192/STM64 OC192/STM64 Optical Intermediate Reach Interface Specifications (IR-2) Copyright © 2017, Juniper Networks, Inc.
Page 94: Understanding Fiber-Optic Cable Signal Loss, Attenuation, And Dispersion
ACX1000 and ACX1100 Universal Access Router Table 28: Supported SONET Standards (continued) Transceiver Monitoring Model Number Type Connector Available Standard Specifications XFP-10G-L-OC192-SR1 SONET/SDH SONET/SDH OC192/STM64 Short OC192/STM64 Optical Reach (SR-1) Interface Specifications XFP-10G-Z-OC192-LR2 SONET/SDH SONET/SDH OC192/STM64 Long OC192/STM64 Optical Reach (LR-2)
Page 95: Calculating Power Budget And Power Margin For Fiber-Optic Cables
(including those from dispersion), and a safety margin for unexpected losses. Related Determining Transceiver Support and Specifications for Juniper Networks Devices Documentation Calculating Power Budget and Power Margin for Fiber-Optic Cables Use the information in this topic and the specifications for your optical interface to calculate the power budget and power margin for fiber-optic cables.
Page 96: Calculating Power Margin For Fiber-Optic Cable
ACX1000 and ACX1100 Universal Access Router can transmit. When you calculate the power budget, you use a worst-case analysis to provide a margin of error, even though all the parts of an actual system do not operate at the worst-case levels. To calculate the worst-case estimate of power budget (P...
Page 97 In both examples, the calculated power margin is greater than zero, indicating that the link has sufficient power for transmission and does not exceed the maximum receiver input power. Related Understanding Fiber-Optic Cable Signal Loss, Attenuation, and Dispersion on page 76 Documentation Copyright © 2017, Juniper Networks, Inc.
Page 99: Transceiver And Cable Specifications
Network Cable and Transceiver Overview for ACX Series, M Series, and MX Series Routers Juniper Networks devices support a variety of fixed and pluggable transceivers and network cable, including multimode and single-mode fiber-optic cable. For a list of transceivers, see “Supported Network Interface Standards by Transceiver for ACX Series,...
Page 100: Supported Network Interface Standards By Transceiver For Acx Series, M Series, Mx Series, And T Series Routers
(JTAC) can help you diagnose the source of the problem. Your JTAC engineer might recommend that you check the third-party optic or cable and potentially replace it with an equivalent Juniper Networks optic or cable that is qualified for the device.
Page 101: Table 30: Supported Ethernet Standards
1000BASE Optical 1000BASE-LX10 Interface Specifications SFP-1GE-SX 1000BASE-SX Gigabit Ethernet 1000BASE Optical Interface Specifications SFP-1GE-T RJ-45 1000BASE-T Gigabit Ethernet 1000BASE-T Copper Interface Specifications SFP-FE20KT13R15 100BASE-BX Fast Ethernet and Gigabit Ethernet Bidirectional SFP Optical Interface Specifications Copyright © 2017, Juniper Networks, Inc.
Page 102 ACX1000 and ACX1100 Universal Access Router Table 30: Supported Ethernet Standards (continued) Transceiver Monitoring Model Number Type Connector Available Standard Specifications SFP-FE20KT15R13 100BASE-BX Fast Ethernet and Gigabit Ethernet Bidirectional SFP Optical Interface Specifications SFP-GE10KT13R14 1000BASE-BX Fast Ethernet and Gigabit Ethernet...
Page 103 10GBASE-Z 10-Gigabit Ethernet 10GBASE Optical Interface Specifications SFPP-10G-DT-ZRC2 SFP+ 10BASE-Z 10-Gigabit Ethernet 10GBASE Optical Interface Specifications SFPP-10G-ER-OTN SFP+ 10GBASE-ER 10-Gigabit Ethernet 10GBASE Optical Interface Specifications SFPP-10G-LR-OTN SFP+ 10GBASE-LR 10-Gigabit Ethernet 10GBASE Optical Interface Specifications Copyright © 2017, Juniper Networks, Inc.
Page 104 ACX1000 and ACX1100 Universal Access Router Table 30: Supported Ethernet Standards (continued) Transceiver Monitoring Model Number Type Connector Available Standard Specifications SFPP-10G-ZR-OTN-XT SFP+ 10GBASE-Z 10-Gigabit Ethernet 10GBASE Optical Interface Specifications SFPP-10GE-ER SFP+ 10GBASE-ER 10-Gigabit Ethernet 10GBASE Optical Interface Specifications SFPP-10GE-LR...
Page 105 40-Gigabit Ethernet 40GBASE-R Optical Interface Specifications 100-Gigabit Ethernet 100GBASE-R Specifications CFP-100GBASE-ER4 100GBASE-ER4 100-Gigabit Ethernet 100GBASE-R Optical Interface Specifications CFP-GEN2-CGE-ER4 100GBASE-ER4 100-Gigabit Ethernet 100GBASE-R Optical Interface Specifications CFP-100GBASE-LR4 100GBASE-LR4 100-Gigabit Ethernet 100GBASE-R Optical Interface Specifications Copyright © 2017, Juniper Networks, Inc.
Page 106 ACX1000 and ACX1100 Universal Access Router Table 30: Supported Ethernet Standards (continued) Transceiver Monitoring Model Number Type Connector Available Standard Specifications CFP-GEN2-100GBASE-LR4 100GBASE-LR4 100-Gigabit Ethernet 100GBASE-R Optical Interface Specifications CFP-100GBASE-SR10 24-fiber 100GBASE-SR10 100-Gigabit Ethernet 100GBASE-R Optical NOTE: Interface Specifications Optical...
Page 107: Table 31: Supported Sonet Standards
SONET/SDH OC12/STM4 OC12/STM4 Long Reach Optical Interface (LR-2) Specifications SFP-OC12-SR SONET/SDH SONET/SDH OC12/STM4 OC12/STM4 Short Optical Interface Reach (SR-1) Specifications SONET OC48/STM16 Specifications SFP-1OC48-IR SONET/SDH SONET/SDH OC48/STM16 OC48/STM16 Optical Intermediate Reach Interface Specifications (IR-1) Copyright © 2017, Juniper Networks, Inc.
Page 108: Calculating Power Budget And Power Margin For Fiber-Optic Cables
You can use the to find information about Hardware Compatibility Tool the pluggable transceivers supported on your Juniper Networks device. To calculate the power budget and power margin, perform the following tasks: Calculating Power Budget for Fiber-Optic Cable on page 90...
Page 109: Calculating Power Margin For Fiber-Optic Cable
Higher-order mode losses Single-mode—None Multimode—0.5 dB Modal and chromatic dispersion Single-mode—None Multimode—None, if product of bandwidth and distance is less than 500 MHz-km Connector 0.5 dB Splice 0.5 dB Fiber attenuation Single-mode—0.5 dB/km Multimode—1 dB/km Copyright © 2017, Juniper Networks, Inc.
Page 110: Understanding Fiber-Optic Cable Signal Loss, Attenuation, And Dispersion
ACX1000 and ACX1100 Universal Access Router The following sample calculation for a 2-km-long multimode link with a power budget ) of 13 dB uses the estimated values from Table 29 on page 78 to calculate link loss (LL) as the sum of fiber attenuation (2 km @ 1 dB/km, or 2 dB) and loss for five connectors (0.5 dB per connector, or 2.5 dB) and two splices (0.5 dB per splice, or 1 dB) as well as...
Page 111: Attenuation And Dispersion In Fiber-Optic Cable
The optical power budget must allow for the sum of component attenuation, power penalties (including those from dispersion), and a safety margin for unexpected losses. Related Determining Transceiver Support and Specifications for Juniper Networks Devices Documentation Copyright © 2017, Juniper Networks, Inc.
Page 113: Initial Installation And Configuration
Initial Installation and Configuration Installation Overview on page 97 Connecting the Router to Power on page 103 Connecting the Router to External Devices on page 109 Installing Components on page 115 Configuring the Router on page 117 Copyright © 2017, Juniper Networks, Inc.
Page 115: Installation Overview
Installing and Connecting an ACX1000 or ACX1100 Router Overview on page 97 Unpacking an ACX1000 or ACX1100 Router on page 98 Parts Inventory (Packing List) for an ACX1000 and ACX1100 Router on page 99 Installing the ACX1000 or ACX1100 Mounting Brackets on page 100...
Page 116: Unpacking An Acx1000 Or Acx1100 Router
General Site Guidelines for ACX Series Routers on page 46 Unpacking an ACX1000 or ACX1100 Router The ACX1000 and ACX1100 routers are shipped in a cardboard carton, secured with foam packing material. The carton also contains an accessory box. CAUTION: ACX1000 and ACX1100 routers are maximally protected inside the shipping carton.
Page 117: Parts Inventory (Packing List) For An Acx1000 And Acx1100 Router
Chapter 11: Installation Overview Parts Inventory (Packing List) for an ACX1000 and ACX1100 Router The ACX1000 and ACX1100 routers are shipped in a cardboard carton, secured with foam packing material. The carton also contains an accessory box. The router shipment includes a packing list. Check the parts you receive in the router shipping carton against the items on the packing list.
Page 118: Installing The Acx1000 Or Acx1100 Mounting Brackets
Insert the four screws at the top and bottom of the bracket, and tighten each partially. Tighten the four screws completely. Repeat the procedure for the other bracket. Figure 19: Installing the Mounting Brackets to the Front of the ACX1000 or ACX1100 Router Figure 20: Installing the Mounting Brackets to the Rear of the ACX1000...
Page 119: Installing The Acx1000 Or Acx1100 Router In The Rack
Chapter 11: Installation Overview Installing the ACX1000 or ACX1100 Router in the Rack NOTE: The router can be installed horizontally in a rack or cabinet. For additional installation options, contact JTAC. To install the router in the rack (see Figure 21 on page...
Page 120: Figure 21: Installing The Front-Mounted Router In The Rack
Site Preparation Checklist for ACX1000 and ACX1100 Routers on page 45 Documentation Installing and Connecting an ACX1000 or ACX1100 Router Overview on page 97 Installing the ACX1000 or ACX1100 Mounting Brackets on page 100 Connecting the ACX1000 or ACX1100 Router to Earth Ground on page 103...
Page 121: Connecting The Router To Power
Connecting the Router to Power Connecting the ACX1000 or ACX1100 Router to Earth Ground on page 103 Connecting DC Power Cables to the ACX1000 or ACX1100 Router on page 105 Connecting AC Power Cords to the ACX1100 Router on page 107...
Page 122: Figure 22: Grounding Points On The Acx1000 And Acx1100 Router
Related Installing and Connecting an ACX1000 or ACX1100 Router Overview on page 97 Documentation Connecting DC Power Cables to the ACX1000 or ACX1100 Router on page 105 Preventing Electrostatic Discharge Damage to an ACX1000 or ACX1100 Router on page 158...
Page 123: Connecting Dc Power Cables To The Acx1000 Or Acx1100 Router
Chapter 12: Connecting the Router to Power Connecting DC Power Cables to the ACX1000 or ACX1100 Router To connect DC power to the router, you need the following tools: Phillips (+) screwdriver, number 2 ESD grounding wrist strap M3 screws and flat washers...
Page 124 ACX1000 and ACX1100 Universal Access Router Secure each power cable lug to the terminal with the flat washers and screw (see Figure 23 on page 107). Apply between 8 lb-in. (0.9 Nm) and 9 lb-in. (1.02 Nm) of torque to each screw. Do not overtighten the screw. (Use a number 2 Phillips screwdriver.)
Page 125: Connecting Ac Power Cords To The Acx1100 Router
ACX1000 and ACX1100 Power Overview on page 41 Documentation Installing and Connecting an ACX1000 or ACX1100 Router Overview on page 97 Connecting the ACX1000 or ACX1100 Router to Earth Ground on page 103 ACX1000 and ACX1100 DC Power Specifications on page 61...
Page 126: Figure 24: Connecting Ac Power To The Router
ACX1000 and ACX1100 Universal Access Router Repeat Step through Step for the remaining power supply. Observe the system LED on the router. If an AC power supply is functioning normally, the system LED lights green steadily. If the system LED is not lit, the power supply is not functioning normally. Repeat the cabling procedures.
Page 127: Connecting The Router To External Devices
Connecting the ACX1000 or ACX1100 Router to an External Alarm-Reporting Device on page 111 Connecting the ACX1000 or ACX1100 Router to External Clocking Devices on page 112 Connecting ACX1000 or ACX1100 Routers to Management Devices To connect external devices and cables to the router, you need the following tools:...
Page 128: Connecting The Router To A Management Console Or Auxiliary Device
ACX1000 and ACX1100 Universal Access Router Figure 26: Ethernet Port CONSOLE/AUX port Console Server Connecting the Router to a Management Console or Auxiliary Device You can connect a console, laptop, modem, or other auxiliary device by connecting a serial cable to the port on the front panel labeled CONSOLE/AUX .
Page 129: Device
Chapter 13: Connecting the Router to External Devices Related Installing and Connecting an ACX1000 or ACX1100 Router Overview on page 97 Documentation General Site Guidelines for ACX Series Routers on page 46 Management Port Connector Pinout Information for ACX Series Routers on page 66...
Page 130: Connecting The Acx1000 Or Acx1100 Router To External Clocking Devices
ACX1000 and ACX1100 Universal Access Router Connecting the ACX1000 or ACX1100 Router to External Clocking Devices The ACX1000 and ACX1100 routers support external clock synchronization for Synchronous Ethernet, T1 or E1 line timing sources, and external inputs. Connecting 1PPS and 10MHz Timing Devices to the Router on page 112...
Page 131 Chapter 13: Connecting the Router to External Devices Initially Configuring the ACX1000 or ACX1100 Router on page 117 Configuring External Clock Synchronization for ACX Series Routers Issue the command to check the status of the port. show chassis synchronization user@host> show chassis synchronization...
Page 133: Installing Components
CHAPTER 14 Installing Components Installing an ACX1000 or ACX1100 Transceiver on page 115 Installing an ACX1000 or ACX1100 Transceiver To install a transceiver: Attach an ESD grounding strap to your bare wrist and connect the strap to one of the ESD points on the chassis.
Page 134 ACX1000 and ACX1100 Universal Access Router Related Front Panel of an ACX1000 Router on page 30 Documentation Uplink Ports on ACX1000 and ACX1100 Routers on page 32 Removing an ACX1000 or ACX1100 Transceiver on page 125 Copyright © 2017, Juniper Networks, Inc.
Page 135: Configuring The Router
Initially Configuring the ACX1000 or ACX1100 Router on page 117 Initially Configuring the ACX1000 or ACX1100 Router The ACX1000 and ACX1100 routers ship with Junos OS preinstalled and ready to be configured when the router is powered on. One 4-GB internal NAND Flash memory device...
Page 136 ACX1000 and ACX1100 Universal Access Router This procedure connects the router to the network but does not enable it to forward traffic. For complete information about enabling the router to forward traffic, including examples, see the Junos OS configuration guides.
Page 137 [edit system services] [edit] root@# set system services telnet (Optional) Display the configuration to verify that it is correct. [edit] root@# show system { host-name host-name; domain-name domain-name; backup-router address; root-authentication { authentication-method (password | public-key); Copyright © 2017, Juniper Networks, Inc.
Page 138 When you have finished configuring the router, exit configuration mode. [edit] root@host# exit root@host> Related ACX1000 and ACX1100 Routers Hardware and CLI Terminology Mapping on page 5 Documentation Protocols and Applications Supported by ACX Series Routers on page 9 Copyright © 2017, Juniper Networks, Inc.
Page 139: Installing And Replacing Components
Replacing an ACX500 or ACX1100 Console or Auxiliary Cable Removing an ACX500 or ACX1100 Console or Auxiliary Cable on page 121 Installing an ACX1000 or ACX1100 Console or Auxiliary Cable on page 122 Removing an ACX500 or ACX1100 Console or Auxiliary Cable...
Page 140: Installing An Acx1000 Or Acx1100 Console Or Auxiliary Cable
Console/Auxiliary Port Connector Pinout on ACX Series Routers on page 65 Documentation Replacing an ACX1000 or ACX1100 Management Ethernet Cable Removing an ACX1000 or ACX1100 Management Ethernet Cable on page 122 Installing an ACX1000 and ACX1100 Management Ethernet Cable on page 122 Removing an ACX1000 or ACX1100 Management Ethernet Cable...
Page 141: Replacing An Acx1000 Or Acx1100 Fiber-Optic Cable
Documentation Replacing an ACX1000 or ACX1100 Fiber-Optic Cable To replace a fiber-optic cable: Disconnecting an ACX1000 or ACX1100 Fiber-Optic Cable on page 123 Connecting an ACX1000 or ACX1100 Fiber-Optic Cable on page 124 Disconnecting an ACX1000 or ACX1100 Fiber-Optic Cable ACX Series routers have field-replaceable unit (FRU) optical transceivers to which you can connect fiber-optic cables.
Page 142: Connecting An Acx1000 Or Acx1100 Fiber-Optic Cable
(see “General Laser Safety Guidelines for Juniper Networks Devices” on page 171). To connect a fiber-optic cable to an optical transceiver installed in an ACX Series router:...
Page 143: Replacing An Acx1000 Or Acx1100 Transceiver
Replacing an ACX1000 or ACX1100 Transceiver Small form-factor pluggable transceivers (SFPs) are optical transceivers that are installed in the front panel of the ACX1000 and ACX1100 router. Transceivers are hot-insertable and hot-removable. Removing an ACX1000 or ACX1100 Transceiver on page 125...
Page 144: Installing An Acx1000 Or Acx1100 Transceiver
ACX1000 and ACX1100 Universal Access Router Use needlenose pliers to pull the ejector handle out from the transceiver. Grasp the transceiver ejector handle, and pull the transceiver approximately 0.5 in. (1.3 cm) out of the router. Using your fingers, grasp the body of the transceiver, and pull it the rest of the way out of the router.
Page 145 Verify that the status LEDs on the front panel indicate that the transceiver is functioning correctly. For more information about the component LEDs, see the “LEDs on ACX1000 and ACX1100 Routers” on page Copyright © 2017, Juniper Networks, Inc.
Page 149: Maintaining Components
Maintaining Components Routine Maintenance Procedures for the ACX1000 and ACX1100 Router on page 131 Maintaining Cables That Connect to ACX1000 and ACX1100 Network Ports on page 131 Maintaining the ACX1000 and ACX1100 Uplink Ports on page 132 Routine Maintenance Procedures for the ACX1000 and ACX1100 Router Purpose For optimum router performance, perform preventive maintenance procedures.
Page 150: Maintaining The Acx1000 And Acx1100 Uplink Ports
Use only an approved alcohol-free fiber-optic cable cleaning kit, such as the Opptex Cletop-S Fiber Cleaner. Follow the directions for the cleaning kit you use. Related Routine Maintenance Procedures for the ACX1000 and ACX1100 Router on page 131 Documentation Troubleshooting Resources for ACX1000 and ACX1100 Routers on page 137...
Page 151 Chapter 17: Maintaining Components PIC 1 Online 8x 1GE(LAN) RJ45 PIC 2 Online 4x 1GE(LAN) SFP, RJ45 Related ACX1000 and ACX1100 Routers Hardware and CLI Terminology Mapping on page 5 Documentation Copyright © 2017, Juniper Networks, Inc.
Page 155: Troubleshooting Components
CHAPTER 18 Troubleshooting Components Troubleshooting Resources for ACX1000 and ACX1100 Routers on page 137 Monitoring System Log Messages on page 138 Verifying Active Alarms on page 138 Understanding Alarm Types and Severity Classes on ACX Series Routers on page 139...
Page 156: Monitoring System Log Messages
ACX1000 and ACX1100 Universal Access Router For more information on front panel LEDs, see “LEDs on ACX1000 and ACX1100 Routers” on page Related Understanding Alarm Types and Severity Classes on ACX Series Routers on page 139 Documentation Verifying Active Alarms on page 138...
Page 157: Understanding Alarm Types And Severity Classes On Acx Series Routers
System alarms indicate a missing rescue configuration. System alarms are preset and cannot be modified, although you can configure them to appear automatically in the J-Web interface display or CLI display. Copyright © 2017, Juniper Networks, Inc.
Page 158: Alarm Severity Classes
ACX1000 and ACX1100 Universal Access Router Alarm Severity Classes Alarms on ACX Series routers have two severity classes: Major (steady red)—Indicates a critical situation on the router that has resulted from one of the following conditions. A red alarm condition requires immediate action.
Page 159: Contacting Customer Support And Returning The Chassis Or Components
PART 6 Contacting Customer Support and Returning the Chassis or Components Contacting Customer Support on page 143 Locating Component Serial Numbers on page 145 Packing and Returning Components on page 147 Copyright © 2017, Juniper Networks, Inc.
Page 161: Contacting Customer Support
Contacting Customer Support on page 143 Contacting Customer Support You can contact Juniper Networks Technical Assistance Center (JTAC) 24 hours a day, 7 days a week in one of the following ways: On the Web, using the Case Manager link at: http://www.juniper.net/support/...
Page 163: Locating Component Serial Numbers
CHAPTER 20 Locating Component Serial Numbers Displaying ACX1000 and ACX1100 Components and Serial Numbers on page 145 ACX1000 and ACX1100 Chassis Serial Number Label on page 146 Displaying ACX1000 and ACX1100 Components and Serial Numbers Before contacting Juniper Networks, Inc. to request a Return Materials Authorization (RMA), you must find the serial number on the router or component.
Page 164: Acx1000 And Acx1100 Chassis Serial Number Label
Figure 34: ACX1000 Chassis Serial Number Label SN: HS0211483603 Serial number ID label Related Displaying ACX1000 and ACX1100 Components and Serial Numbers on page 145 Documentation Returning a Hardware Component to Juniper Networks, Inc. on page 147 Copyright © 2017, Juniper Networks, Inc.
Page 165: Packing And Returning Components
NOTE: Do not return any component to Juniper Networks, Inc. unless you have first obtained an RMA number. Juniper Networks, Inc. reserves the right to refuse shipments that do not have an RMA. Refused shipments are returned to the customer by collect freight.
Page 166: Guidelines For Packing Hardware Components For Shipment
To pack the router for shipment: Retrieve the shipping box and packing materials in which the router was originally shipped. If you do not have these materials, contact your Juniper Networks representative about approved packaging materials. On the console or other management device connected to the Routing Engine, enter CLI operational mode and issue the following command to shut down the router software.
Page 167 Securely tape the box closed. Write the RMA number on the exterior of the box to ensure proper tracking. Related Returning a Hardware Component to Juniper Networks, Inc. on page 147 Documentation Contacting Customer Support on page 143 Copyright © 2017, Juniper Networks, Inc.
Page 169: Safety And Compliance Information
Laser and LED Safety Guidelines and Warnings on page 171 Maintenance and Operational Safety Guidelines and Warnings on page 175 Electrical Guidelines and Warnings on page 181 Agency Approval and Compliance Statements on page 193 Copyright © 2017, Juniper Networks, Inc.
Page 171: General Safety Guidelines And Warnings
General Safety Guidelines and Warnings Definition of Safety Warning Levels on page 153 General Safety Guidelines for Juniper Networks Devices on page 155 General Safety Warnings for Juniper Networks Devices on page 156 Preventing Electrostatic Discharge Damage to an ACX1000 or ACX1100...
Page 172 Documentation Installation Safety Warnings for Juniper Networks Devices on page 164 Maintenance and Operational Safety Warnings for Juniper Networks Devices on page 175 General Electrical Safety Warnings for Juniper Networks Devices on page 181 Copyright © 2017, Juniper Networks, Inc.
Page 173: General Safety Guidelines For Juniper Networks Devices
Chapter 22: General Safety Guidelines and Warnings DC Power Electrical Safety Warnings for Juniper Networks Devices on page 188 General Safety Guidelines for Juniper Networks Devices The following guidelines help ensure your safety and protect the hardware equipment from damage. The list of guidelines might not address all potentially hazardous situations in your working environment, so be alert and exercise good judgment at all times.
Page 174: General Safety Warnings For Juniper Networks Devices
ACX1000 and ACX1100 Universal Access Router General Safety Warnings for Juniper Networks Devices Qualified Personnel Warning on page 156 Restricted-Access Area Warning on page 156 Qualified Personnel Warning WARNING: Only trained and qualified personnel should install or replace the hardware equipment.
Page 175 Varning! Denna enhet är avsedd för installation i områden med begränsat tillträde. Ett område med begränsat tillträde får endast tillträdas av servicepersonal med ett speciellt verktyg, lås och nyckel, eller annan säkerhetsanordning, och kontrolleras av den auktoritet som ansvarar för området. Copyright © 2017, Juniper Networks, Inc.
Page 176: Preventing Electrostatic Discharge Damage To An Acx1000 Or Acx1100
Installation Safety Warnings for Juniper Networks Devices on page 164 Documentation Maintenance and Operational Safety Warnings for Juniper Networks Devices on page 175 General Electrical Safety Warnings for Juniper Networks Devices on page 181 DC Power Electrical Safety Warnings for Juniper Networks Devices on page 188 Preventing Electrostatic Discharge Damage to an ACX1000 or ACX1100 Router Many router hardware components are sensitive to damage from static electricity.
Page 177: Figure 36: Placing A Component Into An Electrostatic Bag
Figure 36: Placing a Component into an Electrostatic Bag NOTE: Figure 36 on page 159 shows a component that is not supported on ACX Series routers. Related Connecting the ACX1000 or ACX1100 Router to Earth Ground on page 103 Documentation Copyright © 2017, Juniper Networks, Inc.
Page 179: Fire Safety Requirements
Establish procedures for protecting people in a fire emergency, provide safety training, and properly provision fire-control equipment and fire extinguishers. In addition, establish procedures to protect your equipment in a fire emergency. Juniper Networks products must be installed in an environment suitable for electronic equipment.
Page 180 To keep warranties effective, do not use a dry chemical fire extinguisher to control a fire at or near a Juniper Networks device. If a dry chemical fire extinguisher is used, the unit is no longer eligible for coverage under a service agreement.
Page 181: Installation Safety Guidelines And Warnings
Balance the load evenly and be sure that your footing is solid. Related General Site Guidelines for ACX Series Routers on page 46 Documentation Installing and Connecting an ACX1000 or ACX1100 Router Overview on page 97 Copyright © 2017, Juniper Networks, Inc.
Page 182: Installation Safety Warnings For Juniper Networks Devices
ACX1000 and ACX1100 Universal Access Router Installation Safety Warnings for Juniper Networks Devices Observe the following warnings before and during hardware equipment installation: Intrabuilding Ports Warning on page 164 Installation Instructions Warning on page 164 Rack-Mounting Requirements and Warnings on page 165...
Page 183: Rack-Mounting Requirements And Warnings
Varoitus Kun laite asetetaan telineeseen tai huolletaan sen ollessa telineessä, on noudatettava erityisiä varotoimia järjestelmän vakavuuden säilyttämiseksi, jotta vältytään loukkaantumiselta. Noudata seuraavia turvallisuusohjeita: Copyright © 2017, Juniper Networks, Inc.
Page 184 ACX1000 and ACX1100 Universal Access Router Router on asennettava telineeseen, joka on kiinnitetty rakennukseen. Jos telineessä ei ole muita laitteita, aseta laite telineen alaosaan. Jos laite asetetaan osaksi täytettyyn telineeseen, aloita kuormittaminen sen alaosasta kaikkein raskaimmalla esineellä ja siirry sitten sen yläosaan.
Page 185 ¡Atención! Para evitar lesiones durante el montaje de este equipo sobre un bastidor, o posteriormente durante su mantenimiento, se debe poner mucho cuidado en que el sistema quede bien estable. Para garantizar su seguridad, proceda según las siguientes instrucciones: Copyright © 2017, Juniper Networks, Inc.
Page 186: Ramp Warning
ACX1000 and ACX1100 Universal Access Router El router debe instalarse en un bastidor fijado a la estructura del edificio. Colocar el equipo en la parte inferior del bastidor, cuando sea la única unidad en el mismo. Cuando este equipo se vaya a instalar en un bastidor parcialmente ocupado, comenzar la instalación desde la parte inferior hacia la superior colocando...
Page 187 Related General Safety Guidelines for Juniper Networks Devices on page 155 Documentation General Safety Warnings for Juniper Networks Devices on page 156 Maintenance and Operational Safety Warnings for Juniper Networks Devices on page 175 Copyright © 2017, Juniper Networks, Inc.
Page 189: Laser And Led Safety Guidelines And Warnings
CHAPTER 25 Laser and LED Safety Guidelines and Warnings General Laser Safety Guidelines for Juniper Networks Devices on page 171 Laser Safety Warnings for Juniper Networks Devices on page 171 General Laser Safety Guidelines for Juniper Networks Devices Devices with single-mode optical interfaces are equipped with laser transmitters, which are considered Class 1 Laser product by the U.S.
Page 190: Class 1 Laser Product Warning
ACX1000 and ACX1100 Universal Access Router Laser Beam Warning on page 173 Radiation from Open Port Apertures Warning on page 173 Class 1 Laser Product Warning WARNING: Class 1 laser product. Waarschuwing Klasse-1 laser produkt. Varoitus Luokan 1 lasertuote. Attention Produit laser de classe I.
Page 191: Laser Beam Warning
Attention Des radiations invisibles à l'il nu pouvant traverser l'ouverture du port lorsqu'aucun câble en fibre optique n'y est connecté, il est recommandé de ne pas regarder fixement l'intérieur de ces ouvertures. Copyright © 2017, Juniper Networks, Inc.
Page 192 öppningar. Related General Safety Guidelines for Juniper Networks Devices on page 155 Documentation General Safety Warnings for Juniper Networks Devices on page 156 Installation Safety Warnings for Juniper Networks Devices on page 164 Copyright ©...
Page 193: Maintenance And Operational Safety Guidelines And Warnings
CHAPTER 26 Maintenance and Operational Safety Guidelines and Warnings Maintenance and Operational Safety Warnings for Juniper Networks Devices on page 175 Maintenance and Operational Safety Warnings for Juniper Networks Devices As you maintain the hardware equipment, observe the following warnings:...
Page 194: Jewelry Removal Warning
ACX1000 and ACX1100 Universal Access Router Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Avvertenza Pericolo di esplosione se la batteria non è installata correttamente.
Page 195: Lightning Activity Warning
Waarschuwing Tijdens onweer dat gepaard gaat met bliksem, dient u niet aan het systeem te werken of kabels aan te sluiten of te ontkoppelen. Varoitus Älä työskentele järjestelmän parissa äläkä yhdistä tai irrota kaapeleita ukkosilmalla. Copyright © 2017, Juniper Networks, Inc.
Page 196: Operating Temperature Warning
ACX1000 and ACX1100 Universal Access Router Attention Ne pas travailler sur le système ni brancher ou débrancher les câbles pendant un orage. Warnung Arbeiten Sie nicht am System und schließen Sie keine Kabel an bzw. trennen Sie keine ab, wenn es gewittert.
Page 197: Product Disposal Warning
Avvertenza L'eliminazione finale di questo prodotto deve essere eseguita osservando le normative italiane vigenti in materia Advarsel Endelig disponering av dette produktet må skje i henhold til nasjonale lover og forskrifter. Copyright © 2017, Juniper Networks, Inc.
Page 198 Varning! Slutlig kassering av denna produkt bör skötas i enlighet med landets alla lagar och föreskrifter. Related General Safety Guidelines for Juniper Networks Devices on page 155 Documentation General Safety Warnings for Juniper Networks Devices on page 156 Copyright © 2017, Juniper Networks, Inc.
Page 199: Electrical Guidelines And Warnings
Devices on page 185 ACX1100 AC Power Electrical Safety Guidelines and Warnings on page 186 ACX1000 and ACX1100 DC Power Electrical Safety Guidelines on page 187 DC Power Electrical Safety Warnings for Juniper Networks Devices on page 188 Site Electrical Wiring Guidelines for Juniper Networks Devices on page 191...
Page 200: Grounded Equipment Warning
ACX1000 and ACX1100 Universal Access Router Grounded Equipment Warning WARNING: The network device is intended to be grounded. Ensure that the network device is connected to earth ground during normal use. Waarschuwing Deze apparatuur hoort geaard te worden Zorg dat de host-computer tijdens normaal gebruik met aarde is verbonden.
Page 201: Midplane Energy Hazard Warning
Varoitus Tässä laitteessa on useampia virtalähdekytkentöjä. Kaikki kytkennät on irrotettava kokonaan, jotta virta poistettaisiin täysin laitteesta. Attention Cette unité est équipée de plusieurs raccordements d'alimentation. Pour supprimer tout courant électrique de l'unité, tous les cordons d'alimentation doivent être débranchés. Copyright © 2017, Juniper Networks, Inc.
Page 202: Power Disconnection Warning
ACX1000 and ACX1100 Universal Access Router Warnung Diese Einheit verfügt über mehr als einen Stromanschluß; um Strom gänzlich von der Einheit fernzuhalten, müssen alle Stromzufuhren abgetrennt sein. Avvertenza Questa unità ha più di una connessione per alimentatore elettrico; tutte le connessioni devono essere completamente rimosse per togliere l'elettricità...
Page 203: Devices
överspänningsskyddet. Related DC Power Electrical Safety Warnings for Juniper Networks Devices on page 188 Documentation General Electrical Safety Guidelines and Electrical Codes for Juniper Networks Devices Install the router in compliance with the following local, national, or international electrical codes: United States—National Fire Protection Association (NFPA 70), United States...
Page 204: Acx1100 Ac Power Electrical Safety Guidelines And Warnings
ACX1000 and ACX1100 Universal Access Router Many router components can be removed and replaced without powering off or disconnecting power to the router. Never install equipment if it appears damaged. Related In Case of an Electrical Accident on page 181...
Page 205: Acx1000 And Acx1100 Dc Power Electrical Safety Guidelines
, the negative lead to the terminal labeled , and the earth ground – to the chassis grounding points. Related DC Power Electrical Safety Warnings for Juniper Networks Devices on page 188 Documentation Copyright © 2017, Juniper Networks, Inc.
Page 206: Dc Power Electrical Safety Warnings For Juniper Networks Devices
ACX1000 and ACX1100 Universal Access Router DC Power Electrical Safety Warnings for Juniper Networks Devices When working with DC-powered equipment, observe the following warnings: DC Power Copper Conductors Warning on page 188 DC Power Disconnection Warning on page 188 DC Power Wiring Terminations Warning on page 190...
Page 207 Varning! Innan du utför någon av följande procedurer måste du kontrollera att strömförsörjningen till likströmskretsen är bruten. Kontrollera att all strömförsörjning är BRUTEN genom att slå AV det överspänningsskydd som skyddar likströmskretsen och tejpa fast överspänningsskyddets omkopplare i FRÅN-läget. Copyright © 2017, Juniper Networks, Inc.
Page 208: Dc Power Wiring Terminations Warning
ACX1000 and ACX1100 Universal Access Router DC Power Wiring Terminations Warning WARNING: When stranded wiring is required, use approved wiring terminations, such as closed-loop or spade-type with upturned lugs. These terminations must be the appropriate size for the wires and must clamp both the insulation and conductor.
Page 209: Site Electrical Wiring Guidelines For Juniper Networks Devices
Related General Safety Warnings for Juniper Networks Devices on page 156 Documentation General Electrical Safety Warnings for Juniper Networks Devices on page 181 Site Electrical Wiring Guidelines for Juniper Networks Devices Distance Limitations for Signaling on page 191 Radio Frequency Interference on page 191...
Page 210 OSP cabling. The addition of primary protectors is not sufficient protection in order to connect these interfaces metallically to OSP wiring. Related General Electrical Safety Guidelines and Electrical Codes for Juniper Networks Devices Documentation on page 185 Copyright © 2017, Juniper Networks, Inc.
Page 211: Chapter 28 Agency Approval And Compliance Statements
Routers on page 195 Compliance Statements for EMC Requirements for ACX1000 and ACX1100 Routers on page 195 Compliance Statements for NEBS for ACX1000 and ACX1100 Routers on page 197 Compliance Statements for Environmental Requirements for Juniper Networks Devices on page 197...
Page 212 ACX1000 and ACX1100 Universal Access Router IEC 60950-1 Information Technology Equipment - Safety - Part 1: General Requirements (with country deviations) EN 60825-1 Safety of Laser Products - Part 1: Equipment Classification, Requirements and User's Guide EN 300 386 V1.3.3 Telecom Network Equipment - EMC Requirements...
Page 213: Routers
Compliance Statements for EMC Requirements for ACX1000 and ACX1100 Routers Documentation on page 195 Compliance Statements for NEBS for ACX1000 and ACX1100 Routers on page 197 Compliance Statements for Acoustic Noise for ACX1000 and ACX1100 Routers on page 195 Compliance Statements for Environmental Requirements for Juniper Networks Devices...
Page 214: Israel
Related Agency Approvals for ACX1000 and ACX1100 Routers on page 193 Documentation Compliance Statements for NEBS for ACX1000 and ACX1100 Routers on page 197 Compliance Statements for Acoustic Noise for ACX1000 and ACX1100 Routers on page 195 Compliance Statements for Environmental Requirements for Juniper Networks Devices on page 197 Copyright ©...
Page 215: Compliance Statements For Nebs For Acx1000 And Acx1100 Routers
GR-1089-CORE. Related Agency Approvals for ACX1000 and ACX1100 Routers on page 193 Documentation Compliance Statements for Acoustic Noise for ACX1000 and ACX1100 Routers on page 195 Compliance Statements for Environmental Requirements for Juniper Networks Devices on page 197 Compliance Statements for Environmental Requirements for Juniper Networks Devices Batteries in this product are not based on mercury, lead, or cadmium substances.

This manual is also suitable for:

Acx1100

Juniper acx1000 User Manual

Chapter 1 System Overview and Architecture

Chapter 2 Chassis Components and Descriptions

Chapter 3 Cooling System and Airflow Components and Descriptions

Chapter 4 Power System Components and Descriptions

Chapter 5 Preparation Overview

Chapter 6 Rack and Cabinet Requirements

Chapter 7 Cooling System and Airflow

Chapter 8 Planning Power Requirements

Chapter 9 Ports and Connectors

Chapter 10 Transceiver and Cable Specifications

Chapter 11 Installation Overview

Chapter 12 Connecting the Router to Power

Chapter 13 Connecting the Router to External Devices

Chapter 14 Installing Components

Chapter 15 Configuring the Router

Chapter 16 Installing and Replacing Components

Chapter 17 Maintaining Components

Chapter 18 Troubleshooting Components

Chapter 19 Contacting Customer Support

Chapter 20 Locating Component Serial Numbers

Chapter 21 Packing and Returning Components

Chapter 22 General Safety Guidelines and Warnings

Chapter 23 Fire Safety Requirements

Chapter 24 Installation Safety Guidelines and Warnings

Chapter 25 Laser and LED Safety Guidelines and Warnings

Chapter 26 Maintenance and Operational Safety Guidelines and Warnings

Chapter 27 Electrical Guidelines and Warnings

Quick Links

Troubleshooting

Related Manuals for Juniper acx1000

Summary of Contents for Juniper acx1000
