Fisher FIELDVUE DVC6200 Instruction Manual page 90

Field Communicator Menu Trees
February 2017
Figure B-9. Calibration (2-4)
Calibration
1 Travel Calibration
2 Relay Adjust
3 Sensor Calibration
4 PST Calibration
Sensor Calibration
1 Pressures Sensors
2 Analog Input
NOTE:
1 PST CALIBRATION IS AVAILABLE FOR INSTRUMENT LEVEL ODV.
2 ANALOG INPUT IS NOT AVAILABLE WHEN THE DIP SWITCH IS SET TO MULTI-DROP.
Figure B-10. Service Tools (3)
Service Tools
1 Device Status
2 Alert Record
3 Diagnostics
4 Variables
5 Maintenance
3-5
Maintenance
1 Performance Tuner
3
2 Stabilize/Optimize
3 Restart Processor
4 Reset Valve Stuck Alert
5 Change to HART 5
5
Run Time Extremes
1 Maximum Recorded Temperature
2 Minimum Recorded Temperature
3 Days Powered Up
4 Number of Power Ups
NOTES:
1 PARTIAL STROKE TEST IS AVAILALBE IN INSTRUMENT LEVEL ODV.
2 SUPPLY PRESSURE AND FALLBACK RECOVERY ARE AVAILABLE FOR AD, PD, ODV.
3 PERFORMANCE TUNER IS AVAILABLE FOR INSTRUMENT LEVEL AD, PD, AND ODV.
4 RESET VALVE STUCK ALERT IS AVAILABLE IN INSTRUMENT LEVEL OD V.
5 THIS MENU ITEM READS CHANGE TO HART 7 WITH HART 5.
90
HART 5
2-4-1
Travel Calibration
1 Auto Calibration
2 Last AutoCal Status
3 Manual Calibration
4 Calibration Record
HART 7
2-4-1
HART 7
Travel Calibration
1 Auto Calibration
2 Last AutoCal Status
1
3 Manual Calibration
2-4-3
4 Calibration Type
5 Calibration Time
6 Calibrator
2
3-2
Alert Record
1 View Alert Records
2 Clear Records
3-3
Diagnostics
1 Stroke Valve
2 Partial Stroke Test
3-4
Variables
1 Travel/Pressure
2 Control Mode
3 Analog Input
4 Temperature
4
5 Travel Counts
6 Characterization
7 Travel History
8 Run Time Extremes
3-4-8
1
3-4-7
Travel History
1 Cycle Counter
2 Travel Accumulator
Instruction Manual
3-4-1
Travel/Pressure
1 Setpoint
2 Travel
3 Drive Signal
4 Supply Pressure
2
5 Pressure A
6 Pressure B
7 Pressure A-B
8 Travel/Pressure Select
9 Fallback Recovery
3-4-2
Control Mode
1 Control Mode
2 Change Control Mode
3 Restart Control Mode
3-4-6
Characterization
1 Input Characterization
2 Custom Characterization
D103605X012
2
