Fisher FIELDVUE DVC6200 Instruction Manual page 74

Parts
February 2017
Figure 7‐2. FIELDVUE DVC6200 Digital Valve Controller Housing Assembly (continued)
APPLY LUBRICANT, SEALANT, OR THREAD LOCK
APPLY LUBRICANT ON ALL O-RINGS UNLESS OTHERWISE SPECIFIED
GE40185 sheet 2 of 3
Figure 7‐3. Gauge Configuration
DOUBLE‐ACTING
FOR PIPE PLUG OPTION REPLACE 47 WITH 66
FOR TIRE VALVE OPTION REPLACE 47 WITH 67
APPLY LUBRICANT, SEALANT, OR THREAD LOCK
APPLY LUBRICANT ON ALL O-RINGS UNLESS OTHERWISE SPECIFIED
GE40185 sheet 3 of 3
74
SECTION A-A
DIRECT‐ACTING
Instruction Manual
SECTION C-C
SCALE 2 : 1
SECTION E-E
SCALE 2 : 1
SECTION F-F
SCALE 2 : 1
REVERSE‐ACTING
D103605X012
