CMA Dishmachines L-1C Owner's Manual page 15

PROBLEM
Counter does not
increment
Running light does not
light while cycle runs
Power light does not light
but glasswasher runs
Wash tank temperature
gauge displays wrong
temperature
Delime switch does not
activate pump motor
*The timer assembly motor (
independently if that is the only component that has failed.
MODEL L-1C INSTALLATION & OPERATION MANUAL Rev. 1.00 A
LIKELY CAUSE
Defective rinse pump motor
Defective counter
Defective timer assembly
(Cam 3)
Defective cycle light
Defective power light
Defective temperature gauge
Defective delime switch
Defective pump motor
) or micro switches (
P/N: 00501.00
SOLUTION
Replace pump motor
P/N: 00416.00
Replace counter
P/N: 03408.50
Replace timer assembly*
P/N: 00408.80
Replace running light (green)
P/N: 00406.60
Replace power light (red)
P/N: 00406.00
Replace temperature gauge
P/N: 201.01
Replace delime switch
P/N: 00475.30
Replace pump motor
P/N: 00201.00
) can be replaced
P/N: 00411.00
