PROBLEM
Start switch requires more
than 1-second activation to
run cycle
Activating fill switch does
not fill glasswasher
Fill water won't shut off
Activating drain switch
does not drain
glasswasher
Detergent pump does not
run
Sani pump does not run
*The timer assembly motor (
independently if that is the only component that has failed.
Rinse pump does not run
Activating detergent primer
switch does not run pump
Activating sani primer
switch does not run pump
Activating rinse primer
switch does not run pump
MODEL L-1C INSTALLATION & OPERATION MANUAL Rev. 1.00 A
LIKELY CAUSE
Defective (Instant Start) ice cube
relay
Defective fill/start switch
Defective water solenoid valve
Defective water solenoid valve
Defective fill/start switch
Defective timer assembly
(Cam 4)
Drain hose is kinked
Defective drain switch
Defective drain valve motor
(Pump will still run)
Defective detergent pump motor
Defective timer assembly
(Cam 2)
Defective sani pump motor
Defective timer assembly
(Cam 5)
) or micro switches (
P/N: 00501.00
Defective rinse pump motor
Defective timer assembly
(Cam 6)
Defective sani/detergent primer
switch
Defective detergent pump motor
Defective sani/detergent primer
switch
Defective sani pump motor
Defective rinse primer switch
SOLUTION
Replace ice cube relay
P/N: 00631.00
Replace fill/start switch
P/N: 03470.01
Replace water solenoid valve
P/N: 03603.10
Replace water solenoid valve
P/N: 03603.10
Replace fill/start switch
P/N: 03470.01
Replace timer assembly*
P/N: 00408.80
Un-kink drain hose
Replace drain switch
P/N: 03406.64
Replace drain valve motor
P/N: 04103.21
Replace pump motor
P/N: 00416.00
Replace timer assembly*
P/N: 00408.80
Replace pump motor
P/N: 00416.00
Replace timer assembly*
P/N: 00408.80
) can be replaced
P/N: 00411.00
Replace pump motor
P/N: 00416.00
Replace timer assembly*
P/N: 00408.80
Replace primer switch
P/N: 03470.00
Replace pump motor
P/N: 00416.00
Replace primer switch
P/N: 03470.00
Replace pump motor
P/N: 00416.00
Replace primer switch
P/N: 03470.00
13
