4.2.

Quick service guide

MODELS: L-1C UNDER COUNTER
TECHNICAL ISSUE
Wash Pump motor will not shut off
Continues cycles
Sustainer heater not working
Machine does not drain
Does not hold water
Tank overflows overnight
Water leaks out of Vacuum Breaker
Wash Pump motor not running
Timer does not rotate
Machine does not fill
Sanitizer pump does not run
MODEL L-1C INSTALLATION & OPERATION MANUAL Rev. 1.00 A
CAUSE
Delimer switch in delime position
Faulty delimer switch
Faulty manual drain switch
Faulty contactor
Faulty #1 micro switch (start/stop)
Faulty start/fill switch
Faulty #1 micro switch
Low water level inside machine
Faulty float switch
Machine not level
Faulty ice cube relay
Faulty #3 micro switch (drain)
Faulty drain valve
Faulty #3 micro switch (drain)
Clogged or defective drain valve
Debris in water Solenoid Valve
Dirty or defective vacuum breaker kit
assy
Faulty check valve
Faulty door switch
Faulty 7th micro switch
Faulty motor contactor
Faulty Start/Fill Switch
Faulty #1 micro switch
Faulty timer motor
Faulty #4 Micro switch
Debris inside water solenoid valve or
Faulty valve
Delimer switch in wrong position
Faulty 5th micro switch
Faulty sanitizer pump motor
SOLUTION
Flip to NORMAL position
Replace switch, P/N 00475.30
Replace switch, P/N 03406.62
Replace contactor, P/N 00404.82
Replace switch, P/N 00411.00
Replace switch, P/N 03470.01
Replace switch, P/N 00411.00
Add water to tank to activate float switch, adjust
water cam on timer
Replace switch, P/N 13463.10
Level machine
Replace relay, P/N 00631.00
Replace switch, P/N 00411.00
Replace drain valve, P/N 04103.00
Replace switch, P/N 00411.00
Clean and/ or replace drain valve, P/N 04103.00
Clean or replace valve P/N 03604.00
Clean or replace internal parts, P/N 03623.00
Replace check valve, P/N 00715.00
Replace switch, P/N 00411.00
Replace switch, P/N 00411.00
Replace contactor, P/N 00404.82
Replace switch, P/N 03470.01
Replace switch, P/N 00411.00
Replace motor assembly, P/N 00501.00
Replace switch, P/N 00411.00
Clean or replace valve P/N 03604.00
NORMAL
Switch to position
Replace switch, P/N 00411.00
Replace motor, P/N 00416.00
