- Page 1 CMDPH-1A Mini-DisplayPort to HDMI Converter Operation Manual CMDPH-1A...
- Page 2 Disclaimers The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
-
Page 3: Safety Precautions
Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, ... -
Page 4: Table Of Contents
Table of Contents 1. Introduction .................. 1 2. Application .................. 1 3. Package Content ................ 1 4. System Requirements ..............1 5. Features ..................1 6. Specifications ................2 7. Operation Control and Functions ..........3 Front Panel ................3 Rear Panel ................3 Top Panel ................4 8. Connection and Installation . -
Page 5: Introduction
1. Introduction The external Mini-DisplayPort to HDMI Converter is a high-speed device that can be configured into 1 or 2 lanes and has a 1.62/2.7 Gbit/s data rate. This device features differential input signals to HDMI, current-steering differential output signals and the ability for both PCIe and Mini DisplayPort to use the same I/O because they are electrically compatible. -
Page 6: Specifications
• Level shifter and configurable output for HPD signals received through the HDMI/DVI connector • Power and audio sent and received through the USB port, no power supply is required • Easy to install and operate 6. Specifications TMDS Clock Frequency 2.7Gbps Input ports 1 x Mini-DisplayPort (Male type), 1 x USB... -
Page 7: Operation Control And Functions
7. Operation Control and Functions 7.1 Front Panel INPUT MDP & USB INPUT: Connect these cables to your input sources output ① ports in order to send and receive a signal as well as receive power. 7.2 Rear Panel HDMI OUT HDMI OUT: This slot is to connect to the output display such as an HDTV or ①... -
Page 8: Top Panel
7.3 Top Panel Dual Mode MDP to HDMI with USB Audio Reset RESET: Press this key only when the image is not displayed. Press it ① repeatedly until the image turns off. -
Page 9: Connection And Installation
8. Connection and Installation Apple NB Apple HDTV... -
Page 10: Acronyms
Acronyms Acronym Complete Term HDCP High-bandwidth Digital Content Protection Mini DisplayPort...
