- Page 1 HDMI to CV/SV Converter - with HDMI Bypass Operation Manual CM-388...
- Page 2 TABLE OF CONTENTS 1. Introduction................2. Main Features................3. Package Contents..............4. Hardware Description..............4.1 Front Panel................4.2 Rear Panel................5. Connections and Installation............ 6. Specifications................
-
Page 3: Main Features
1. Introduction The HDMI to CV/SV Converter is designed to convert digital signal from HDMI (or DVI + Coaxial) source to analog signal of NTSC or PAL system, with L/R stereo audio. Besides S-Video and Composite Video outputs, it also provides one bypass HDMI output to deliver original signal, and a Coaxial output to send S/PDIF digital audio to audio amplifier. -
Page 4: Package Contents
INPUT A Both video and audio from HDMI source* HDMI - > Bypass, output original video and audio from HDMI COAXIAL -> Output digital audio from HDMI OUTPUT A CV + L/R -> Output analog video / audio converted from HDMI SV + L/R ->... -
Page 5: Hardware Description
4. Hardware Description The following sections describe the hardware components. 4.1 Front Panel POWER CM-388 HDMI REPEAT WITH VIDEO OUTPUT 1 Power LED: The LED indicator will illuminate when the unit is powered on. 4.2 Rear Panel NTSC COAXIAL COAXIAL... -
Page 6: Connection And Installation
5. Connection and Installation Amplifier HDMI TV 6. Specifications Input ports 1 x HDMI type A, 1 x Coaxial Output ports 1 x HDMI type A, 1 x Coaxial, 2 x Stereo R/L RCA jack, 1 x Composite-Video RCA jack, 1 x S-Video mini-din Power Supply 5V/2.6A DC (US/EU standards, CE/FCC/UL certified) Dimensions (mm) - Page 7 20071206 MPM-CM380...
- Page 8 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw...
