Summary of Contents for KanexPro DVSP8HD
- Page 1 DVSP8HD DVI 1x2 Splitter with Full HD 1080p and HDCP Management...
- Page 2 04. Warranty ......5 Notice KanexPro™ reserves the right to make changes in the hardware, packaging and any accompanying docu- mentation without prior written notice...
-
Page 3: Specifications
Specifications Video Input/output Input: 1 DVI Input Connector: Female DB24+5 Input Level: T.M.D.S 2.9/3.3V Input Impedance: 50 Ohms Output: 8 DVI, 4 DVI Output Connector: Female DB24+5 Output Level: T.M.D.S 2.9V/3.3V Output Impedance: 50 Ohms Video General Gain: 0dB Bandwidth: 340 MHz (10.2 Gbit/s) Video Signal: DVI 1.0 Standard DVI-D Full digital T.M.D.S Signal, HDMI 1.3 Max Time-delay: 5nS (±1nS) CMRR: >90dB @20Hz~20K Hz Maximum Pixel Clock: 165 MHz Resolution Range: Up to 1920x1200 or 1080p @ 60 Hz HDCP: Compliant with High-bandwidth Digital Content Protection (HDCP) using DVI and HDMI 1.3 Standards... - Page 4 Unit Layout...
- Page 5 KanexPro’s entire liability and Customer’s exclusive remedy shall be, at KanexPro option, either return of the price paid for the product, or repair or replacement of the Product that does not meet this Limited Warranty and which is returned to KanexPro with a copy of custom- ers’ receipt. This Limited Warranty is void if failure of the Product has resulted from accident, abuse, or misapplication. Any replacement...
- Page 6 Brea, California KanexPro.com...
