Model TVE-810
interface
Serial port
Alarm in
Alarm out
Others Protocol
Consumption
Operating temperature
Operating humidity
Dimensions
Weight
Model TVE-1610
Video/Audio Video compression
input
Analog video input
Audio compression
Audio input
Bi-directional audio
input
Audio output
Video/Audio Recording resolution
output
Frame rate
Video bit rate
Stream type
Audio bit rate
Dual stream
External Network port
interface
Serial port
Alarm in
Alarm out
Others Protocol
Consumption
Operating temperature
Operating humidity
Dimensions
Weight
58
1 RS-485 port, half-duplex
8
4
Support CGI, PSIA and ONVIF
Max. 10W
-10 to +55 C° (14 to 131 °F)
10 to 90%
315 x 45 x 200 mm
1396 g (3.08 lb.)
H.264/MPEG4/MJPEG
16-ch, BNC connector (1.0 Vp-p, 75 Ω);
G.711
16-ch,
1-ch, 3.5 mm interface (2.0 Vp-p, 1 kΩ)
1-ch, 3.5 mm interface (Linear, 600 Ω)
WD1 / 4CIF / 2CIF / CIF
Main stream:
WD1 / 4CIF / 2CIF / CIF @ 25 fps (P) / 30 fps (N)
Sub stream:
WD1 @ 2 fps / 4CIF @4 fps / 2 CIF @ 8fps / CIF
@12 fps / QCIF @ 25 fps(P) 30fps(N)
32 kbps to 8192 kbps
Video/ Video & Audio
64 kbps
Support
1, RJ45 10 M / 100 M adaptive Ethernet port
1 RS-485 port, half-duplex
16
4
Support CGI, PSIA and ONVIF
Max. 22W
-10 to +55 C° (14 to 131 °F)
10 to 90%
440 x 45 x 274 mm
2486 g (5.48 lb.)
TVE-110/410/810/1610 H.264 IP Video Encoder User Manual
