Function Description
SOCKS SOCKet Secure (SOCKS) is an Internet protocol that routes network packets
between a client and server through a proxy server. This feature is useful if
the encoder is located on a local network behind a firewall, and Email
notifications, FTP uploads, alarms, and such need to be sent to a destination
outside the local network (such as the Internet).
NAT A NAT (Network Address Translation) is used for network connection.
Select the port mapping mode: Auto or Manual.
HTTPS HTTPS (Hyper Text Transfer Protocol Secure) ensures the data transferred
is encrypted using Secure Socket Layer (SSL) or Transport Layer Security
(TLS). HTTPS provides authentication of the web site and associated web
server that one is communicating with and create a secure channel over an
insecure network.
Bonjour Bonjour is enabled by default and the video encoder can be automatically
detected by operating systems and clients that support this protocol.
IP Address Filter You can allow or forbid access by specified IP addresses to the encoder by
enabling IP Address Filter.
802.1x The IEEE 802.1X standard is supported by the network cameras, and when
the feature is enabled, the camera data is secured and user authentication is
needed when connecting the camera to the network protected by the IEEE
802.1X.
Advanced Configure the multicast address, remote alarm host and Telnet.
To configure TCP/IP settings:
1. Click Configuration
TCP/IP. The TCP/IP window appears.
2. Enter the required settings:
Option
NIC Type
18
> Remote Configuration
Description
Network interface card (NIC) is a device used to connect the
encoder to a network. Select the NIC type used from the drop-
down list.
Default value is Auto.
TVE-110/410/810/1610 H.264 IP Video Encoder User Manual
> Network Settings >
