Model TVE-410
Video/Audio output Recording resolution
Frame rate
Video bit rate
Stream type
Audio bit rate
Dual stream
External interface Network interface
Serial port
Alarm in
Alarm out
Others Protocol
Consumption
Operating temperature
Operating humidity
Dimensions
Weight
Model TVE-810
Video/Audio Video compression
input
Analog video input
Audio compression
Audio input
Bi-directional audio
input
Audio output
Video/Audio Recording resolution
output
Frame rate
Video bit rate
Stream type
Audio bit rate
Dual stream
External Network port
TVE-110/410/810/1610 H.264 IP Video Encoder User Manual
WD1 / 4CIF / 2CIF / CIF / QCIF
Main stream:
WD1 / 4CIF / 2CIF / CIF @ 25 fps (P) / 30 fps (N)
Sub stream:
WD1 @ 2 fps / 4CIF @4 fps / 2 CIF @ 8fps / CIF
@12 fps / QCIF @ 25 fps(P) 30fps(N)
32 kbps to 8192 kbps
Video/ Video & Audio
64 kbps
Support
1, RJ45 10 M / 100 M adaptive Ethernet interface
1 RS-485 interface, half-duplex
4
2
Support CGI, PSIA and ONVIF
Max. 8W
-10 to +55 C° (14 to 131 °F)
10 to 90%
114 x 48 x 128 mm
557 g (1.23 lb.)
H.264/MPEG4/MJPEG
8-ch, BNC connector (1.0 Vp-p, 75 Ω)
G.711
8-ch,
1-ch, 3.5mm interface (2.0 Vp-p, 1 kΩ)
1-ch, 3.5mm interface (Linear, 600Ω)
WD1 / 4CIF / 2CIF / CIF / QCIF
Main stream:
WD1 / 4CIF / 2CIF / CIF @ 25 fps (P) / 30 fps (N)
Sub stream:
WD1 @ 2 fps / 4CIF @4 fps / 2 CIF @ 8fps / CIF @12
fps / QCIF @ 25 fps(P) 30fps(N)
32 kbps to 8192 kbps
Video/ Video & Audio
64 kbps
Support
1, RJ45 10 M / 100 M adaptive Ethernet port
57
