Interlogix TVE-110 User Manual page 24

• IP server: Enter the server address for IPServer.
• ezDDNS: Enter the host name. It will automatically register it online.
4. Click Save to save the settings.
To configure Email settings:
1. Click Configuration
to set the IPv4 Address, IPv4 Subnet Mask, IPv4 Default Gateway and the
Preferred DNS Server.
2. Click the Configuration
Email. The Email Settings window appears.
3. Check Authentication
login user name and password.
4. Enter the required settings.
Option
Authentication
SMTP server
SMTP port
Enable SSL
Interval
Attached Snapshot
Sender
Sender's address
Choose receiver
Receiver
Receiver's address
5. Click Test to the test email settings.
Note: We recommend that you test the email settings after entering values in
the email window.
6. Click Save to save the settings.
To configure NetHDD settings:
Note: Ensure that the network storage device is available within the network
and is properly connected. Also the network storage device must be
configured with NAS or IP SAN mode.
20
> Remote Configuration
> Remote Configuration
if your mail server requires authentication. Enter the
Description
If your mail server requires authentication, check this checkbox
to use authentication to log in to this server and enter the login
User Name and Password.
Enter the SMTP server's IP address.
Enter the SMTP port. The default TCP/IP port for SMTP is 25.
Check the box to enable SSL if it is required by the SMTP
server. This feature is optional.
The interval represents the time range in between the alarm
images being sent. For example, if you set the interval at two
seconds, the second alarm image will be sent two seconds after
the first alarm image.
Check the box if you want to send email with attached alarm
JPEG images.
Enter the name of the sender of the email.
Enter the sender's email address.
Select an email recipient. Up to three receivers can be selected.
Enter the name of the receiver of the email.
Enter the email address of the receiver.
TVE-110/410/810/1610 H.264 IP Video Encoder User Manual
> Network Settings
> Network Settings
> TCP/IP
>
