Interlogix TVE-110 User Manual page 56

Item Name
7. Timeline
8. Time bar
9. Video and audio control
10. Recording type
11. Time selection box
To play back a recording:
1. Click the Playback
appears.
2. Select a camera and date for play back. Click Search.
3. Click Play to start playback.
4. Use the playback control toolbar to manually control playback.
5. To select an exact time to start playback, drag the time bar to where you want
playback to start . You can also enter the exact time into the time selection
box and click
52
Description
Allows you to jump forwards or backwards in time. The
timeline moves left (oldest video) to right (newest video).
Click a location on it for where you want playback to start.
It also shows the type of recording by color coding.
Time of actual playback.
Drag the bar to an exact spot where you want playback to
start.
Description of the color coding of recording types shown in
the timeline.
Green indicates continuous recording. Red indicates
alarm/event recording. Light green indicates manual
recording.
Enter an exact time to start playback.
button on the menu toolbar. The Playback window
.
TVE-110/410/810/1610 H.264 IP Video Encoder User Manual
Play back frame-by-frame. This allows you to
carefully examine an event frame-by-frame as it
happens
Stop playback for all cameras.
Capture a snapshot of a video image. The
image is saved on the computer.
Download video files found in the search.
Start/stop video clip during playback. Sections of
a recording can be saved to an external storage
device.
Turn audio on/off.
Switch to full screen mode.
